Product Overview
The Woodward 5461-655 Final Driver Module provides precise control for output stages such as valves, actuators, and motors in industrial automation systems. It is designed to work seamlessly within the MicroNet TMR (Triple Modular Redundant) architecture, ensuring fault-tolerant performance and stable load management.
Moreover, the module supports GCB (Generator Circuit Breaker) condition communication, load ramp-up, and feedback alarms, maintaining system reliability under all conditions.
Key Attributes:
- Brand: Woodward
- Model: 5461-655
- Product Type: Final Driver Module
- Country of Origin: United States
- Repair Lead Time: 3–7 days
- Availability: In Stock
Functional Highlights
The 5461-655 incorporates advanced load control and diagnostic features to enhance generator and motor operation. It integrates communication, feedback, and alarm management to maintain synchronized operation and prevent equipment faults.
Main Functions:
- GCB Condition Monitoring – Detects breaker status via discrete inputs (DI 08 & DI 11).
- Automatic Load Ramp-Up – Smoothly increases load upon GCB closure.
- Load Share Self-Test – Performs internal diagnostic checks, confirming via relay output.
- CAN Bus Member Detection – Switches to droop mode if network communication is missing.
- Feedback and Alarm System – Provides GCB, tie-breaker, and load share alarms for fault indication.
These functions ensure balanced load distribution and system stability across connected modules.
Technical Specifications
| Parameter | Description |
|---|---|
| Part Number | 5461-655 |
| Manufacturer | Woodward |
| System Type | MicroNet TMR Final Driver Module |
| Power Supply | Dual power inputs, LED fault indication |
| Relay Outputs | R01–R08 for status and alarm communication |
| Diagnostic Features | CPU 040 and CPU 5200 synchronization |
| Environmental Range | Industrial-grade, suitable for continuous operation |
| Typical Repair Time | 3–7 working days |
In addition, the module undergoes comprehensive startup diagnostics to ensure readiness before application execution.
System Integration
The 5461-655 module is an essential component in Woodward’s MicroNet TMR control systems, providing the final drive signal to actuators or valves. It integrates effortlessly with load-sharing modules, generator controllers, and CAN bus networks.
For instance, during power-up, it coordinates with CPU modules for diagnostics and synchronization, ensuring the system transitions smoothly into operational mode.
Therefore, the 5461-655 is ideal for generator load management, motor control, and power plant automation systems requiring robust, redundant operation.
Details
| Weight | 0.3 kg |
|---|
