The Woodward 5417-027 is a dedicated 10-foot low-density analog cable assembly. This cable provides a reliable interconnection for analog signals within NetCon control systems. Moreover, its design ensures accurate transmission of critical process variables like speed and pressure. Consequently, you maintain signal integrity between I/O modules and field sensors.

Precision Wiring for Analog Signals

This low-density cable assembly features individually shielded twisted pair conductors. This construction effectively minimizes cross-talk and electromagnetic interference. Furthermore, the cable connects seamlessly to specific Woodward NetCon analog I/O card connectors. Therefore, it delivers a plug-and-play solution for clean and stable analog signal acquisition.

Physical Construction and Durability

The 5417-027 assembly measures exactly 10 feet (approximately 3.05 meters) in length. It utilizes industrial-grade connectors that withstand repeated mating cycles. Additionally, the cable jacket offers robust resistance to oils, chemicals, and abrasion. This durability guarantees long-term performance in challenging plant floor environments.

Detailed Technical Parameters

Complete Specifications for Woodward 5417-027:

• Manufacturer & Model: Woodward 5417-027

• Product Type: Cable Assembly, Low-Density, Analog

• Compatible System: Woodward NetCon Control System

• Cable Length: 10 feet (3.05 meters)

• Conductor Type: Likely uses twisted pair wires with individual shielding.

• Shielding: Features overall foil and/or braid shield for noise immunity.

• Connector Type: Proprietary connectors matching NetCon analog I/O modules.

• Number of Conductors/Pins: “Low-Density” suggests a connector with fewer pins (e.g., 9-25 pins).

• Signal Type: Designed specifically for analog voltage or current signals (e.g., 4-20mA, +/-10VDC).

• Jacket Material: Industrial-grade PVC or similar, resistant to oil and abrasion.

• Wire Gauge: Likely 22 AWG or 24 AWG for analog signal integrity.

• Voltage Rating: Typically rated for 300V.

• Temperature Rating: Operates within standard industrial ranges (e.g., -20°C to 80°C).

• Primary Function: Interconnects NetCon processor or communication modules with analog I/O cards.

• Color: Standard industrial cable coloring, often gray or beige.

Ensuring Signal Integrity and Simplifying Installation

Using this factory-assembled cable eliminates potential wiring errors during installation. Its predefined length and connectors also save significant time and labor. Ultimately, the Woodward 5417-027 is a critical component for building a reliable and noise-free analog measurement system.
