Overview
The GE UR-8NH CT/VT Module enhances the Universal Relays series by providing eight standard Current Transformers (CTs). It allows easy replacement of faulty units, upgrades older systems, or adds CT/VT functionality to relays that initially lacked it.
Key Features
- Versatile Signal Monitoring: Supports up to 24 analog CT/VT signals, compatible with 1 A and 5 A ratings for flexible system integration.
- Comprehensive Diagnostics: Continuously monitors hardware health during operation and performs automated checks at startup.
- Advanced Health Monitoring: Tracks system conditions using Advanced Health Diagnostics, displaying alerts on the LCD or via EnerVista UR software.
Other modules in the Universal Relays series provide additional protections, including high-impedance fault detection and ground fault protection.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | UR-8NH |
| Manufacturer | GE Multilin |
| Dimensions | 6” L x 7” W x 1.5” H |
| Weight | 1.15 kg |
| Signal Capacity | 24 analog CT/VT inputs |
| CT Ratings | 1 A / 5 A |
| Diagnostic Features | Startup checks, continuous health monitoring, Advanced Health Diagnostics |
| Software | EnerVista UR |
Applications
The GE UR-8NH module delivers reliable CT/VT signal monitoring for industrial power systems. Its compact design, robust diagnostic capabilities, and modular integration ensure dependable operation in critical control environments.
Details
| Weight | 1.15 kg |
|---|
