The TRICONEX 9674-810 functions as a 10-position termination panel specifically designed to connect Triconex I/O modules with field devices in safety-critical applications. This high-quality termination board provides a reliable interface between control system electronics and industrial sensors, actuators, and switches. Engineers select the 9674-810 for installations requiring organized, secure field wiring in harsh environments.
Robust Construction and Field Wiring Features
We manufacture the TRICONEX 9674-810 with ruggedized construction materials that withstand vibration, temperature extremes, and corrosive atmospheres typical in process industries. Corrosion-resistant terminals ensure long-term signal integrity even in chemical plants or offshore oil platforms. Additionally, color-coded terminals with clear markings simplify installation and reduce wiring errors during system commissioning.
Terminal Positions: 10 points for organized field device connections.
Module Compatibility: Accepts various Triconex analog and digital I/O modules.
Terminal Material: Corrosion-resistant construction for harsh environment durability.
Identification: Color-coded terminals with clear permanent markings.
Construction: Ruggedized design meeting industrial installation requirements.
Physical Specifications and Application Versatility
The 9674-810 measures approximately 20.3 cm in height, 12.7 cm in width, and 5.1 cm in depth, providing compact termination for control cabinet installations. The unit weighs roughly 1.4 kg and features integrated mounting points for secure DIN rail or panel attachment. This termination board supports diverse applications including temperature sensor connections for chemical process monitoring, safety switch integration for conveyor systems, control valve positioning in oil wells, and speed sensor interfaces for railway transportation.
Technical Specifications Overview
| Parameter | Specification |
|---|---|
| Manufacturer | Triconex (Schneider Electric) |
| Part Number | 9674-810 |
| Product Type | Digital Output Terminal Board |
| Terminal Positions | 10 |
| Module Compatibility | Multiple Triconex I/O module types |
| Terminal Material | Corrosion-resistant |
| Identification System | Color-coded with clear markings |
| Dimensions (HxWxD) | ~20.3 cm x 12.7 cm x 5.1 cm |
| Weight | ~1.4 kg |
| Mounting | DIN rail or panel mount compatible |
| Environmental Rating | Ruggedized for harsh conditions |
Common Application Configurations
Process Control: Connects analog input modules to temperature sensors in chemical plants for safe process monitoring.
Industrial Automation: Interfaces digital I/O modules with conveyor safety switches for reliable emergency stops.
Oil and Gas: Links analog output modules to control valves for precise wellhead flow management.
Transportation: Connects digital I/O modules to train speed sensors for safe velocity monitoring and control.
