The Triconex 8306A is a high-performance power supply expansion unit designed to provide reliable backup power for critical industrial control systems. It delivers stable 24 VDC regulated output and ensures continuous operation, enhancing overall system reliability in demanding industrial environments.
Technical Overview
The 8306A operates on a 24 VDC ±10% input, with maximum power consumption of 48 W and efficiency exceeding 88% typical. Its compact design, measuring 6.1 × 17.8 × 41.3 cm, allows easy installation in standard 19-inch equipment racks while maintaining proper ventilation. The unit features overload protection (105–150%), overvoltage protection (135%), and low ripple and noise under 100 mV peak-to-peak, ensuring safe and stable operation.
Key Features
- Provides regulated 24 VDC output with ±1.5% voltage tolerance
- High efficiency design (>88%) minimizes energy loss
- Integrated overload and overvoltage protection safeguards equipment
- Compact rack-mountable design with natural convection cooling
- UL, cUL, and CE certified for industrial safety compliance
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 8306A |
| Manufacturer | Triconex |
| Product Type | Power Supply Expansion Unit |
| Input Voltage | 24 VDC ±10% |
| Output Voltage | 24 VDC regulated |
| Power Consumption | 48 W max |
| Efficiency | >88% typical |
| Voltage Regulation | ±1.5% |
| Ripple & Noise | <100 mV peak-to-peak |
| Overload Protection | 105–150% of rated output |
| Overvoltage Protection | 135% of rated output |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | –40°C to 85°C |
| Humidity Range | 5–95%, non-condensing |
| Dimensions | 6.1 × 17.8 × 41.3 cm (2.4″ × 7.0″ × 16.3″) |
| Weight | 2.0 kg (4 lbs 6.5 oz) |
| Cooling Method | Natural convection |
| Safety Standards | UL, cUL, CE certified |
Installation Guidelines
- Mount the 8306A in a standard 19-inch rack.
- Maintain at least 2 cm clearance for proper ventilation.
- Connect 24 VDC input power with correct polarity.
- Ensure all connections are secure before powering the unit.
- Verify status indicators show normal operation before use.
Package Contents
- 1 × Triconex 8306A Power Supply Expansion Unit
- Installation and operation manual
- Mounting hardware kit
- Connection cables and accessories
- Express shipping via FedEx, UPS, or DHL
Origin, Dimensions, and Weight
- Country of Origin: USA
- Dimensions: 6.1 × 17.8 × 41.3 cm (2.4″ × 7.0″ × 16.3″)
- Weight: 2.0 kg (4 lbs 6.5 oz)
Applications
The Triconex 8306A provides backup and regulated power for industrial control systems, ensuring continuous operation of PLCs, safety systems, and critical monitoring modules. Its efficient design, robust protections, and rack-mount compatibility make it ideal for manufacturing, energy, and automation environments.
Details
| Weight | 2 kg |
|---|---|
| Dimensions | 61 × 178 × 413 mm |
