Product Overview
The Triconex 4000043-310 functions as a precision cable assembly for connecting analog input signals to Triconex safety controllers. It provides a reliable shielded interconnection between field termination assemblies and I/O modules. This assembly ensures signal integrity for continuous operation in demanding industrial applications.
Key Technical Specifications
Engineers select this cable for its robust construction and guaranteed performance in critical safety loops. Its design minimizes signal degradation over the connection path. Below, we detail the core technical parameters.
| Specification | Details |
|---|---|
| Product Type | Analog Input Signal Cable Assembly |
| Manufacturer | Invensys Triconex (Schneider Electric) |
| Part Number | 4000043-310 |
| Series | Triconex Safety Instrumented Systems (SIS) |
| Primary Function | Connects analog input signals from field terminations to Triconex I/O modules |
| Cable Construction | Shielded twisted-pair conductors for noise immunity |
| Connector Type A | Designed for Triconex analog input modules |
| Connector Type B | Designed for Triconex termination panels (e.g., 4000043-310 specific pinout) |
| Shielding | Full foil and braid shielding with drain wire for grounding |
| Insulation Material | High-grade industrial PVC or PLENUM-rated jacket |
| Temperature Rating | Suitable for continuous operation in industrial control cabinets |
| Length | Standard predefined length for optimal signal routing |
Detailed Features and Benefits
Precision Signal Transmission for Critical Analog Loops
The Triconex 4000043-310 maintains signal fidelity between field terminations and the safety controller. It preserves the accuracy of 4-20 mA and voltage signals essential for safety functions. Consequently, you achieve reliable process measurements without degradation from the interconnection.
Superior Noise Rejection with Full Shielding
This cable assembly incorporates both foil and braid shielding around each twisted pair. The shielding prevents electromagnetic interference from affecting sensitive analog signals. Therefore, you maintain signal integrity even in electrically noisy industrial environments.
Factory-Tested Reliability for Continuous Operation
Invensys Triconex designs this assembly for uninterrupted performance in demanding applications. It undergoes rigorous testing to ensure reliable connections in safety-critical paths. As a result, you minimize the risk of signal loss or intermittent failures.
Precision Connectors for Secure Termination
The 4000043-310 features high-quality connectors that mate securely with Triconex modules and panels. They provide positive locking to prevent accidental disconnection during maintenance. This design ensures stable, long-term connections in vibrating environments.
Optimized Length for Clean Cabinet Wiring
This cable comes in a predefined length ideal for routing within standard Triconex cabinets. It eliminates excess cable that can cause clutter and signal coupling issues. Thus, you achieve professional installations with improved airflow and accessibility.
Direct Compatibility with Triconex Analog Infrastructure
You can use this cable with Triconex analog input modules and matching termination panels. It maintains the impedance and signal characteristics required for high-integrity measurements. This compatibility simplifies ordering and ensures proper system operation.
Details
| Weight | 0.595 kg |
|---|---|
| Dimensions | 18 × 225 × 209.7 mm |
