The Triconex 3000604-100 is a 16-channel digital input module for Triconex safety instrumented systems. This module interfaces with safety sensors including emergency stop buttons and pressure switches. Engineers use it to monitor critical field devices in SIL 3 certified applications. The 3000604-100 delivers fast response times essential for safety functions. Its robust design ensures reliable operation in demanding industrial environments.
Technical Specifications
| Specification | Details |
|---|---|
| Product Type | Digital Input Module |
| Part Number | 3000604-100 |
| Series | Triconex Safety System |
| Input Channels | 16 Points |
| Input Type | 24 Vdc Dry Contact or Sourcing |
| Response Time | <1 Millisecond |
| Input Voltage Range | 18-30 Vdc |
| Input Current | 6 mA per Channel |
| Isolation | 1500 Vdc Field to Logic |
| Module Width | 40 mm (Single Slot) |
| Height | 250 mm |
| Depth | 200 mm |
| Weight | 1.2 kg |
| Power Consumption | 5 W |
| MTTF | >100,000 Years |
| Connection Type | 50-Pin Connector |
| Operating Temperature | 0°C to 60°C |
Key Features
The 3000604-100 delivers a fast response time of less than 1 millisecond for critical safety applications. It achieves a mean time to failure exceeding 100,000 years for exceptional reliability. The module scales from small applications to large systems with thousands of I/O points. Extensive configurability allows customization for specific application requirements. A 50-pin connector interfaces with standard Triconex termination panels for easy integration.
Applications
Oil and Gas: Engineers use the 3000604-100 to monitor safety systems on offshore platforms and pipelines. The module interfaces with emergency shutdown buttons and pressure switches reliably.
Chemical Processing: The module monitors safety systems in chemical plants including distillation columns and reactors. It detects abnormal conditions for immediate protective action.
Power Generation: Power plants use this module to monitor boilers, turbines, and auxiliary equipment. Its fast response ensures safe operation of power generation assets.
Details
| Weight | 2.85 kg |
|---|---|
| Dimensions | 41.2 × 17.8 × 6.2 mm |
