The Yokogawa SNT401-53 Optical ESB Bus Repeater Master Module extends the communication range of the ESB Bus within the ProSafe-RS safety system. It enables stable optical signal transmission across distances up to 10 km, depending on configuration. By pairing with the SNT501-53 slave module, it supports both star and chain-type topologies for safety controller and node connectivity.

Function and Compatibility

• Primary Function: Extends ESB Bus communication using optical signal transmission.
• Compatibility: Works with safety control units such as SSC10S/D, SSC50S/D, SSC60S/D, S2SC70S/D, and node units like SNB10D.
• Connection Requirements: Connects from ESB Bus Coupler Modules SEC401/SEC402 or ESB Bus Interface Module SSB401 via ESB Bus cables.
• Types Available: With or without a terminator, depending on installation needs.

Technical Specifications

Key Features

• Extends ESB Bus communication distance up to 10 km with optical links.
• Supports multiple topologies, including star and chain, for flexible design.
• Lightweight build of only 0.3 kg simplifies installation in compact spaces.
• Meets ANSI/ISA S71.04 G3 corrosion resistance standards for harsh environments.
• Operates reliably across wide temperature ranges from -20°C to 70°C.
• Pairs seamlessly with SNT501-53 slave modules to complete the ESB Bus network.

Application

The SNT401-53 module ensures stable communication between safety controllers and nodes in ProSafe-RS systems. It provides the backbone for industrial safety networks, guaranteeing reliable data flow across extended distances in mission-critical environments.
