Seamless Connection Between S7-200 and Modern PCs
The Siemens 6ES7901-3DB30-0XA0 USB/PPI cable enables fast, reliable programming of S7-200 PLCs. It draws power directly from your computer, eliminating the need for additional adapters. The plug-and-play design ensures immediate setup without technical complications.
Key Advantages of 6ES7901-3DB30-0XA0
- Easy Integration: Connects USB ports to PPI for all S7-200 series PLCs.
- Automatic Baud Detection: Supports speeds from 9.6 kbit/s up to 187.5 kbit/s.
- LED Status Indicators: Real-time Tx, Rx, and PPI activity display.
- Electrical Isolation: Protects PLCs and PCs with 500V AC isolation.
- No External Power Required: Operates entirely via USB connection.
Detailed Technical Specifications
| Feature | Specification |
|---|---|
| Product Code | 6ES7901-3DB30-0XA0 |
| Manufacturer | Siemens |
| Compatible Series | SIMATIC S7-200 |
| Interface Type | USB to RS-485 (PPI) |
| Maximum Speed | 187.5 kbit/s |
| Supported Protocol | PPI (10/11 bit) |
| Cable Length | 3 meters |
| LED Indicators | Tx, Rx, PPI status |
| Power Supply | 5V DC via USB port |
| Isolation | 500V AC electrical protection |
| Weight | 300 grams |
| Country of Origin | Germany |
Product Dimensions and Weight
- Length: 3 meters
- Weight: 300 grams
- Cable Type: USB to RS-485 PPI
Frequently Asked Questions
Which Siemens PLCs are compatible?
The 6ES7901-3DB30-0XA0 works with all S7-200 series PLCs and expansion modules.
Do I need additional drivers?
Yes, install Siemens programming software and USB drivers for proper operation.
Can I use multiple cables simultaneously?
Yes, the multi-master feature allows network communication with multiple S7-200 devices.
What do the three LED indicators represent?
Green LEDs indicate USB transmission, USB reception, and PPI network activity, respectively.
Details
| Weight | 0.3 kg |
|---|
