Overview
SEW EURODRIVE 252767 PCV80A-F200-R4-V19-SEW is an advanced optical sensor module designed for high-precision industrial automation. It delivers exceptional measurement accuracy with robust electronic and mechanical design, supporting fast and reliable data acquisition in complex industrial environments.
Key Features
- High-resolution optical sensor module PCV80A-F200-R4-V19-SEW for industrial automation systems
- CMOS global shutter camera ensures precise object detection and minimal motion blur
- Integrated LED lighting (red) provides reliable illumination for measurement
- Supports three function inputs and three programmable switch outputs
- RS485 interface with binary code output enables fast data communication
- IP67 protection guarantees operation in harsh environments
- Designed to withstand shock and vibration according to EN 60068 standards
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | SEW EURODRIVE |
| Part Number | 252767 |
| Model | PCV80A-F200-R4-V19-SEW |
| Sensor Type | Optical Sensor Module |
| Passage Speed | ≤ 8 m/s |
| Measuring Range | Max. 10,000 m |
| Light Type | Integrated red LED |
| Read Distance | 80 mm |
| Depth of Focus | ±10 mm |
| Reading Field | 40 × 25 mm |
| Ambient Light Limit | 100,000 lux |
| Resolution | ±0.1 mm |
| Camera Type | CMOS, global shutter |
| Processor Clock Rate | 600 MHz |
| Computation Speed | 4800 MIPS |
| MTTFd | 20 years |
| Service Life | 10 years |
| Diagnostic Coverage | 0% |
| LED Display | 7 LEDs (communication, alignment aid, status info) |
| Operating Voltage | DC 15–30 V PELV |
| No-Load Current | Max. 200 mA |
| Power Consumption | 3 W |
| Interface | RS485, binary code output |
| Transfer Rate | 38,400 – 230,400 bit/s |
| Termination | Switchable terminating resistor |
| Query Cycle Time | ≥10 ms |
| Input Type | 1 to 3 function inputs, programmable |
| Output Type | 1 to 3 switch outputs, PNP, programmable, short-circuit protected |
| Switching Voltage | Operating voltage |
| Switching Current | 150 mA each output |
| Standard Conformity | EN 61000-6-4:2007 + A1:2011, EN 61000-6-2:2005, EN 60068 |
Dimensions & Weight
- Compact design supports flexible mounting in automation systems
- Height: 70 mm | Width: 70 mm | Depth: 50 mm
- Mass: Approx. 160 g
Origin
- Manufactured in Germany by SEW EURODRIVE
Details
| Weight | 0.16 kg |
|---|---|
| Dimensions | 70 × 70 × 50 mm |
