The Schneider Electric TSXP57153M is a central processor unit for the Modicon Momentum automation platform. This module serves as the core control brain for your M580 PAC system, executing complex logic and managing communications. It delivers high-performance processing capabilities for demanding industrial applications. Consequently, it ensures reliable and deterministic control for critical manufacturing and infrastructure processes.
Processing Architecture and Memory Specifications
This processor features a powerful architecture for fast execution of control programs. It includes substantial user memory for storing extensive application logic and data. The TSXP57153M supports multiple programming languages defined in the IEC 61131-3 standard. Therefore, engineers can program it using ladder logic, function block diagram, or structured text.
Furthermore, the module manages real-time data exchange with local and distributed I/O modules. It integrates seamlessly into the Modicon X80 rack using a high-speed backplane connection. The processor maintains a real-time clock for accurate time-stamping of process events and alarms.
Communication and Network Connectivity
The TSXP57153M provides multiple embedded communication ports for network integration. It typically includes Ethernet ports for plant-wide connectivity using Modbus TCP/IP. The module also supports various other industrial fieldbus and network protocols via dedicated communication modules. This flexibility enables integration into diverse and hybrid automation architectures.
Physical Design and Operating Parameters
The processor module installs into a designated slot within the Modicon X80 rack. Its design ensures efficient heat dissipation for stable operation in industrial environments. The module draws its operating power directly from the system’s redundant power supply backplane. LED indicators on the front fascia provide clear status information for power, run mode, and errors.
The robust construction of this Schneider Electric component ensures long-term reliability. For professionals sourcing such critical control hardware, platforms like Alibaba provide access to a global supply chain for compatible industrial automation parts.
Detailed Technical Specifications
The table below details the core technical parameters of the TSXP57153M processor module.
| Parameter Category | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Product Series | Modicon M580 / X80 |
| Model Number | TSXP57153M |
| Module Type | Central Processing Unit (CPU/PAC) |
| Controller Type | Programmable Automation Controller (PAC) |
| Embedded Ports | Ethernet, USB for programming/service |
| Supported Protocols | Modbus TCP/IP, Ethernet/IP, etc. |
| Programming Standard | IEC 61131-3 (LD, FBD, ST, etc.) |
| Memory | Substantial for program & data storage |
| Backplane Connection | Modicon X80 High-Speed Rack |
| Power Supply | From X80 Rack Backplane |
| Status Indicators | LED for Power, Run, Fault, Communication |
| Typical Applications | Complex process control, machine automation, SCADA |
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 110 × 55 × 90 mm |
