Delivering Stable and Reliable Power for Control Systems
The Schneider Electric TSXLES65 is a premium power supply module for automation systems. It provides clean, regulated DC voltage to the Telemecanique TSX Micro or Premium PLC rack. This module ensures stable operation for the processor, I/O modules, and connected sensors. Consequently, it is a foundational component for building reliable industrial control panels.
Technical Specifications and Electrical Performance
This power supply module converts standard single-phase AC line voltage to system DC power. Its design includes input protection and meets rigorous industrial safety standards. Furthermore, the TSXLES65 offers sufficient capacity for medium-sized PLC configurations.
Detailed Technical Parameters
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric (formerly Telemecanique) |
| Model Number | TSXLES65 |
| Product Series | Telemecanique TSX Micro / Premium |
| Product Category | PLC Power Supply Module / Rack Power Supply |
| Primary Input Voltage | 100-240 VAC (Single Phase, Auto-ranging) |
| Input Voltage Frequency | 47-63 Hz |
| Main Output Voltage | 24 VDC |
| Rated Output Current | 4.0 Amps |
| Total Output Power | 96 Watts (24VDC x 4A) |
| Ripple & Noise | < 150 mV peak-to-peak (typical) |
| Input Protection | Integrated fuse and surge protection |
| Efficiency | Typically > 80% |
| Power Factor | > 0.9 (at full load, high line) |
| Hold-up Time | Typically 20 ms at full load after AC loss |
| Overload Protection | Automatic current limiting, thermal shutdown |
| Status Indicators | LED for “Power OK” / “24V Present” |
| Operating Temperature Range | 0°C to 60°C (derating above 40°C may apply) |
| Storage Temperature Range | -40°C to 85°C |
| Module Dimensions (H x W x D) | Standard TSX rack-width module |
| Module Weight | Approximately 0.7 kg |
| Mounting | Plugs directly into the TSX PLC base/rack |
| Output Connections | Supplies the backplane; auxiliary 24V terminals often provided |
| Safety Certifications | cULus, CE, and other international standards |
| Internal Energy Storage | Minimal (for hold-up via filter capacitors) |
| Mean Time Between Failures (MTBF) | High (typical of industrial power supplies) |
Key Features and System Integration
The TSXLES65 powers the entire PLC rack, including the CPU and all I/O modules. Its auto-ranging input accepts global mains voltages from 100VAC to 240VAC. The module provides a clean 24VDC bus for both logic and sensor power requirements. Moreover, its integrated diagnostics and protection safeguard downstream components from electrical faults. This makes it a critical and reliable power source for machine control applications.
Application Context and Sizing
This power supply is suitable for TSX Micro and Premium PLCs with moderate I/O counts. It supports racks filled with digital I/O, analog modules, and communication interfaces. Engineers must calculate the total current draw of all modules to ensure capacity. The TSXLES65 often powers external 24VDC sensors and devices via its auxiliary terminals. Therefore, proper sizing is essential for a stable and trouble-free control system.
Installation and Wiring Guidelines
Installation involves connecting AC mains (L, N, PE) to the module’s input terminals. The unit then plugs into the dedicated power supply slot on the TSX rack. Always use appropriate wire gauges and follow local electrical codes for installation. Furthermore, ensure proper grounding to maintain safety and reduce electrical noise.
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 110 × 55 × 90 mm |
