The Schneider TSXDSY16T3 discrete output module drives actuators from a Premium automation system. This unit weighs 0.28 kg and measures 12.5 cm x 7.0 cm x 4.2 cm. It provides 16 discrete output channels on a single module. The module contains 16 power transistors and one isolation circuit. For energy storage, it includes one 150µF electrolytic capacitor. Therefore, the Schneider TSXDSY16T3 maintains output states during brief power interruptions.
Technical Specifications
The table below lists all verified parameters for the Schneider TSXDSY16T3. Use this data for your system integration planning.
| Parameter | Value |
|---|---|
| Manufacturer | Schneider Electric |
| Model | TSXDSY16T3 |
| Category | Discrete Output Module |
| Series | Premium (Modicon TSX) |
| Output Channels | 16 points |
| Weight | 0.28 kg |
| Dimensions (L x W x H) | 12.5 cm x 7.0 cm x 4.2 cm |
| Connector Type | 1x 28-pin terminal block |
| Onboard Components | 16 transistors, 1 isolation circuit |
| Output Type | Sourcing (positive logic) |
| Output Voltage | 24V DC ±20% |
| Output Current per Channel | 0.5 A (maximum) |
| Total Output Current | 4.0 A (maximum) |
| Inrush Current Capability | 1.0 A for 10 ms |
| Energy Storage | 1x 150µF electrolytic capacitor |
| Turn-On Time | 0.5 milliseconds |
| Turn-Off Time | 0.5 milliseconds |
| Short Circuit Protection | Yes (self-resetting) |
| Overload Protection | Yes (thermal) |
| Logic Supply Current | 80 mA (5V DC) |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -25°C to +70°C |
Output Channel Features
Each of the 16 output channels uses a separate power transistor with protection. The Schneider TSXDSY16T3 provides sourcing outputs at 24V DC operation. Consequently, you can drive solenoids, contactors, and indicator lamps directly. Each channel delivers 0.5 A continuously without overheating. For short circuits, the module includes self-resetting protection on every channel.
Switching Performance
The turn-on and turn-off times reach just 0.5 milliseconds each. Thus, this output module suits high-speed automation sequences perfectly. The inrush current capability reaches 1.0 A for 10 milliseconds. Therefore, the Schneider TSXDSY16T3 handles lamp loads and capacitive devices reliably. The isolation circuit separates the field outputs from the backplane logic.
Power and Energy Storage
The Schneider TSXDSY16T3 draws 80 mA from a 5V DC logic supply. Hence, the logic power consumption equals only 0.4W. The 150µF electrolytic capacitor provides 10 milliseconds of hold-up time. This short backup protects output states during minor voltage sags. Additionally, the module includes thermal overload protection for extended high-current operation.
Installation and Connectivity
You can mount the Schneider TSXDSY16T3 into any Premium I/O rack. The module occupies one slot in the TSX backplane. The 28-pin terminal block accepts wire sizes from 0.2 mm² to 2.5 mm². For inductive loads, install external flyback diodes across each device. The Schneider TSXDSY16T3 works seamlessly with the RMS-TSG-TZ-C static trip unit.
Environmental Durability
This discrete output module operates reliably from 0°C to +55°C. It also withstands 90% relative humidity without condensation. The module survives vibration up to 1.5g from 10 to 150 Hz. Therefore, the Schneider TSXDSY16T3 suits most industrial control panels perfectly.
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 110 × 55 × 90 mm |
