The Schneider TSX CPPACC1 functions as a communication interface adapter for the Modicon TSX Micro automation platform. This unit enables the connection of TSX Micro processors to various industrial networks and programming tools. Consequently, it provides flexible communication options for both system configuration and real-time data exchange.
Core Technical Specifications
We engineered the Schneider TSX CPPACC1 for reliable and versatile connectivity in TSX Micro-based control systems. The table below details its essential physical and electronic parameters:
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Model Number | TSX CPPACC1 |
| Product Type | Communication Interface Adapter |
| Compatibility | Modicon TSX Micro Processors (e.g., TSX 37-22) |
| Primary Interface | Serial connection to TSX Micro CPU (via specific port) |
| Network/Device Ports | Typically provides one or two ports (e.g., RS-232C, RS-485) |
| Supported Protocols | Uni-Telway, Modbus (Master/Slave), ASCII, Char-N |
| Mounting | Clips directly onto TSX Micro CPU front panel |
| Power Supply | Derived directly from the CPU via the connection |
| Operating Temperature | 0°C to +60°C |
| Dimensions | Compact, integrated with TSX Micro form factor |
| Weight | Approx. 0.1 kg (0.22 lbs) |
Direct CPU Mounting for Space Savings
The TSX CPPACC1 clips directly onto the front panel of a compatible TSX Micro processor. This design requires no additional cabinet space or separate DIN-rail mounting. Therefore, it maintains the compact footprint of your TSX Micro system while adding communication capabilities.
Multiple Protocol Support for Versatility
This adapter supports several communication protocols, including Uni-Telway, Modbus, ASCII, and Char-N. You can configure it as a Modbus master to read data from slave devices or as a slave for SCADA access. As a result, the Schneider TSX CPPACC1 adapts to a wide range of application requirements.
Flexible Physical Interfaces
The adapter typically provides physical ports for RS-232C or RS-485 communication networks. This allows connection to programming terminals, operator interfaces, drives, or remote I/O. Consequently, you gain flexibility in connecting the TSX Micro to both simple and complex network architectures.
Seamless Programming and Debugging
You can use the TSX CPPACC1 to establish a direct serial link for programming the TSX Micro CPU with PL7 Junior or Pro software. It provides a reliable connection for online monitoring, program transfers, and debugging tasks. Hence, it simplifies the initial setup and ongoing maintenance of your control system.
Reliable Power and Signal Integrity
The adapter draws its operating power directly from the TSX Micro CPU via the connection interface. This eliminates the need for an external power supply and reduces wiring complexity. Additionally, it maintains signal integrity for reliable communication over the specified cable distances.
Robust Design for Industrial Environments
Schneider designed the TSX CPPACC1 to withstand the typical conditions found in industrial control panels. It operates reliably within a temperature range of 0°C to +60°C. Its robust construction ensures long-term dependability in factory floor or process automation settings.
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 110 × 55 × 90 mm |
