Schneider Electric designed the TSXPSY3610M to provide robust power distribution for Modicon Premium automation platforms. This unit delivers 3.6 A at 24 VDC to support CPU and I/O modules. It ensures stable operation across demanding industrial control applications.
Key Technical Specifications
The TSXPSY3610M module features a rack-mountable housing with precise engineering tolerances. It measures 100 millimeters in height and 166 millimeters in depth. This unit weighs approximately 1.05 kilograms for secure backplane installation.
| Specification | Detail |
|---|---|
| Input Voltage | 100 to 240 VAC, auto-ranging |
| Output Voltage | 24 VDC at 3.6 A |
| Output Power | 86.4 W maximum |
| Energy Storage | Integrated hold-up capacitor for 20 ms buffering |
| Interfaces | One screw-type input terminal, one output connector |
| Component Count | Single PCB with thermal protection and fuse |
| Dimensions | 100 x 56 x 166 mm (H x W x D) |
Moving to installation, this power supply slides directly into the Premium rack slot. You insert it and lock it with the integrated latch mechanism. Consequently, the unit establishes immediate electrical contact with the backplane without additional wiring.
Design and Application Focus
Engineers rely on the TSXPSY3610M for consistent power in high-I/O count systems. The design incorporates overcurrent protection to prevent damage to downstream components. Furthermore, the hold-up capacitor provides brief energy storage during power interruptions. This feature allows the system to ride through momentary voltage dips without resetting.
Unlike external power bricks, this module integrates fully with the Premium backplane architecture. You can power the processor, communication modules, and all I/O cards from a single source. Additionally, the front-panel LED indicator shows output status for immediate diagnostic feedback.
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 110 × 55 × 90 mm |
