Overview
The Schneider Electric 140XSM00200 provides professional manual input simulation for Modicon Quantum discrete input modules. I use this 16-switch tool to test module operation without connecting field devices, saving setup time and ensuring reliable system verification. Its compact industrial design allows easy placement in control panels or workbenches for troubleshooting and training purposes.
Key Features
- I include 16 independent toggle switches to simulate discrete input signals efficiently.
- I ensure direct compatibility with Quantum discrete modules such as 140DAI74000 and 140DAI54000.
- I design the simulator to draw power from the Quantum module, requiring no external power supply.
- I provide a sturdy industrial-grade enclosure for consistent performance in laboratory or field environments.
- I simplify commissioning, diagnostics, and maintenance training with straightforward manual operation.
Technical Specifications
| Parameter | Description |
|---|---|
| Brand | Schneider Electric |
| Model / Part Number | 140XSM00200 |
| Product Type | 16-Switch Discrete Input Simulator |
| Platform | Modicon Quantum |
| Switch Type | Manual toggle switches |
| Channel Count | 16 discrete inputs |
| Compatible Modules | 140DAI74000, 140DAI54000, Quantum discrete I/O series |
| Connection | Direct connection to Quantum I/O modules |
| Application | Testing, diagnostics, commissioning, and training |
| Country of Origin | USA |
| Dimensions | 22 × 12 × 6 cm |
| Weight | 1.1 kg (2.43 lb) |
Testing Advantages
- Verify Quantum input module functionality without field device wiring.
- Test control logic and signal response in a controlled, repeatable environment.
- Troubleshoot system operation quickly with immediate switch feedback.
- Commission new installations efficiently before connecting actual field devices.
- Train maintenance personnel safely on input signal behavior and system logic.
Frequently Asked Questions
How does the simulator operate?
Each toggle switch manually simulates a field device input. Toggle switches on/off to check module responses.
Which modules are compatible with this tool?
The 140XSM00200 works with 140DAI74000, 140DAI54000, and other Quantum discrete input modules.
Does it require external power?
No external power is needed. It draws necessary voltage from the connected Quantum module.
Can it simulate different voltage levels?
It supports standard Quantum input voltages. Verify your module datasheet for exact compatibility.
Is specialized training necessary?
No. Anyone familiar with Quantum systems can operate this simulator safely and effectively.
Package Contents
- 1 × 140XSM00200 16-Switch Input Simulator
- User manual with operating instructions
Details
| Weight | 1.1 kg |
|---|---|
| Dimensions | 220 × 120 × 60 mm |
