Schneider Electric engineered the 140ACO13000 analog output module for precision control. This Modicon Quantum component delivers eight independent channels for versatile process management. Its robust design ensures stable operation in diverse industrial environments.
High-Performance Output and Safety Features
The 140ACO13000 module provides exceptional channel-to-bus isolation for safety. This isolation withstands 1780 V AC for one full minute during operation. Each channel supports a configurable output range from 4 to 20 mA. Furthermore, the module quickly detects and reports any open circuit fault conditions.
This unit achieves a fast update time of only 5 ms for all eight channels. Consequently, it delivers highly responsive control for dynamic automation processes. The setting time reaches ±0.1% of the final value in just 3.2 milliseconds.
Reliable Operation and Integration
The 140ACO13000 requires an external 6-30 VDC power supply for its field circuits. It dissipates a maximum of 5 W of power during standard operation. The module draws a maximum current of 550 mA from the system backplane.
It operates reliably within a temperature range of 0°C to +60°C. Clear LED indicators provide immediate visual status feedback. This Schneider Electric module carries the CE mark for compliance with international standards.
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Product Line | Modicon Quantum |
| Part Number | 140ACO13000 |
| Module Type | Analog Output Module |
| Number of Channels | 8 |
| Output Signal Range | 4 to 20 mA |
| Open Circuit Fault Detection | Yes |
| Isolation (Channel to Bus) | 1780 V AC for 1 min |
| Update Time (All Channels) | 5 ms |
| Setting Time (±0.1% Final Value) | 3.2 ms |
| External Power Supply | 6 – 30 VDC |
| Maximum Power Dissipation | 5 W |
| Maximum Current Draw | 550 mA |
| Operating Temperature | 0°C to +60°C |
| LED Indicators | Yes |
| Compliance | CE Marking |
| Weight | 0.91 kg (2.00 lbs) |
Details
| Weight | 0.48 kg |
|---|---|
| Dimensions | 55 × 180 × 260 mm |
