The DAP 208 from Schneider Electric serves as a high-density discrete output module for industrial automation systems. Engineers rely on this unit to control actuators, contactors, and indicator lamps reliably. It forms an integral part of the broader TSX/Modicon Premium I/O family.

Core Hardware Specifications and Physical Design

This output module features a standard Eurocard form factor measuring approximately 100 mm x 160 mm. The unit weighs roughly 0.35 kg, facilitating easy installation in Premium racks. Its rugged enclosure protects internal components from dust and vibration. Furthermore, the front panel includes clear LED indicators for each output channel.

Output Channel Configuration and Ratings

The DAP 208 provides eight discrete outputs using industrial-grade relay technology. Each relay supports switching voltages up to 240 VAC or 24 VDC. The contacts handle continuous currents up to 2 A per channel with a maximum inrush of 5 A. This configuration makes it suitable for direct control of small motors and solenoid valves.

Isolation and Protection Features

Each output channel includes optical isolation rated at 1500 Vrms for system protection. This isolation prevents ground loops and protects the backplane from voltage transients. Additionally, the module incorporates built-in snubber circuits for inductive load switching. These features extend relay contact life significantly in demanding applications.

Technical Specifications

Installation and Integration Benefits

The DAP 208 plugs directly into any standard Premium rack position without special tools. Its screw terminal block simplifies field wiring and maintenance access. Users can mix this module with analog and discrete input modules freely. Consequently, it offers flexible configuration for diverse control panel requirements.
