The Schneider ASBDEP217 functions as a high-density digital input module for the Modicon Premium automation platform. It efficiently captures status signals from various field devices like limit switches and push buttons. This module ensures reliable communication between industrial sensors and the control system.
Advanced Input Processing and Channel Configuration
We engineer this module to handle 32 discrete input channels in a single compact unit. Each channel accepts 24 VDC signals from standard industrial sensors and switches. The module includes built-in LED indicators for immediate visual status feedback. Consequently, technicians can quickly troubleshoot field wiring issues without special tools.
Technical Specifications and Physical Characteristics
The ASBDEP217 utilizes optical isolation to protect the internal circuitry from electrical transients. It features a typical input current of 7 mA at 24 VDC for reliable signal detection. The module responds rapidly to input state changes, ensuring real-time process monitoring. This design supports high-speed applications requiring immediate PLC response.
| Specification | Details |
|---|---|
| Product Model | ASBDEP217 |
| Module Type | Digital Input Module |
| Number of Channels | 32 discrete inputs |
| Input Voltage Rating | 24 VDC |
| Input Current | 7 mA typical at 24 VDC |
| Isolation Voltage | 1500 Vrms between field and logic |
| Response Time | < 4 ms (OFF to ON) / < 8 ms (ON to OFF) |
| Backplane Current Draw | 280 mA from 5 VDC |
| Physical Dimensions | Standard Modicon Premium format |
| Module Weight | Approximately 0.35 kg (0.77 lb) |
| Terminal Type | Removable screw terminal block |
| Status Indicators | Green LED per channel |
Seamless Integration with Premium Automation Systems
You can configure this module effortlessly using the Unity Pro software environment. The Schneider ASBDEP217 automatically maps input data to the processor memory space. It supports both local rack mounting and remote I/O configurations via the bus. Therefore, system architects enjoy tremendous flexibility when designing control networks.
Furthermore, this module excels in applications requiring high-density signal monitoring. Industries like automotive manufacturing, packaging, and material handling benefit from its compact design. The module’s filtering options help eliminate false triggering from electrical noise. This reliability ensures consistent operation in harsh industrial environments.
We source this high-quality module from Schneider Electric, a world leader in industrial automation solutions. As part of the Modicon Premium family, it guarantees long-term availability and technical support. Choosing the ASBDEP217 means investing in dependable digital input processing for your machinery.
Technical Specifications Overview
| Specification | Details |
|---|---|
| Product Model | ASBDEP217 |
| Module Type | Digital Input Module |
| Number of Channels | 32 discrete inputs |
| Input Voltage Rating | 24 VDC |
| Input Current | 7 mA typical at 24 VDC |
| Isolation Voltage | 1500 Vrms between field and logic |
| Response Time | < 4 ms (OFF to ON) / < 8 ms (ON to OFF) |
| Backplane Current Draw | 280 mA from 5 VDC |
| Physical Dimensions | Standard Modicon Premium format |
| Module Weight | Approximately 0.35 kg (0.77 lb) |
| Terminal Type | Removable screw terminal block |
| Status Indicators | Green LED per channel |
| Compatible Software | Unity Pro, PL7 Pro |
| Series | Modicon Premium |
| Manufacturer | Schneider Electric |
