The Schneider 140XBP01600 serves as a 16-slot rack backplane for the Modicon Quantum automation platform. This unit provides the essential physical and electrical backbone for your control system, and it reliably supports various local, remote, and distributed I/O modules.
By establishing the core communication infrastructure, this backplane connects the Quantum CPU to all peripheral modules. Consequently, it ensures stable and high-speed data exchange across the entire system. Furthermore, its robust construction guarantees consistent performance in demanding industrial environments.
Technical Specifications and Physical Data
We define the Schneider 140XBP01600 by its precise mechanical and environmental parameters. The following table details its core technical specifications.
| Parameter | Specification |
|---|---|
| Manufacturer / Brand | Schneider Electric |
| Product Line | Modicon Quantum |
| Part Number | 140XBP01600 |
| EAN / Barcode | 3595861127371 |
| Number of Slots | 16 |
| Supported I/O Types | Local, Remote, Distributed Modules |
| Mounting Support | Mounting Plate |
| Fixing Method | Screw |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Weight | 9.00 lbs (4.08 kg) |
Application and System Integration Role
This backplane acts as the central framework for building a scalable Quantum system. Engineers can populate its 16 slots with a customized mix of communication, analog, and digital modules. Therefore, it allows for a highly flexible I/O configuration that meets specific application demands.
The wide operating and storage temperature ranges ensure durability across varied climates. As a result, the 140XBP01600 suits diverse applications from factory floors to remote outdoor installations. Ultimately, its reliable performance establishes it as a foundational component for robust industrial automation solutions.
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 55 × 180 × 260 mm |
