Delivering Precision and Speed for Demanding Automation Tasks
The Schneider 140EHC10500 is a high-speed counter module for the Modicon Quantum platform. This module provides five independent channels for fast and accurate pulse counting. Consequently, it is ideal for applications requiring precise measurement of speed, position, or flow.
Engineered for Reliable Operation in Varied Industrial Conditions
Designed by Schneider Electric, this module operates reliably across a wide temperature range. It functions in environments from 0°C to 60°C and withstands storage from -40°C to 85°C. Furthermore, the 140EHC10500 handles high humidity levels up to 95% non-condensing.
Comprehensive Technical Specifications and Physical Data
The Schneider 140EHC10500 combines multiple I/O points with robust protective features. Its detailed technical parameters are outlined in the following specification table.
| Parameter Category | Specification |
|---|---|
| Manufacturer & Model | Schneider Electric 140EHC10500 |
| Product Category | High-Speed Counter Module |
| Compatible System | Modicon Quantum Series |
| Number of Channels | 5 Independent High-Speed Counter Channels |
| Digital Inputs | 8 Dedicated Input Points |
| Digital Outputs | 8 Dedicated Output Points |
| Module Weight | 0.40 kg (0.88 lbs) |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Operating/Storage Humidity | Up to 95% RH (non-condensing) |
| Output Protection | Internal Short-Circuit Protection |
| Supported Rack Types | Local, Distributed, or Remote Quantum Racks |
| Maximum Operating Altitude | 5000 meters above sea level |
| Recommended Environment | Clean indoor setting, free of corrosive chemicals |
| Primary Interface | Quantum backplane connector for data/power |
Facilitating Flexible System Integration and Protection
This module integrates seamlessly into local, distributed, or remote Quantum rack configurations. Its built-in output short-circuit protection enhances system durability and safety. Therefore, the 140EHC10500 offers significant adaptability for complex system architectures.
A Core Component for Advanced Motion and Process Control
With its five high-speed channels, this module efficiently handles tasks like encoder feedback and batch counting. The eight complementary I/O points provide direct control for associated devices. Ultimately, the Schneider 140EHC10500 delivers the performance needed for sophisticated automation and data acquisition systems.
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 110 × 55 × 90 mm |
