The Schneider 140DDO15310C provides reliable discrete output capabilities for Modicon Quantum automation platforms. This module drives relays, solenoid valves, and indicators with consistent switching performance. You can integrate this unit seamlessly into new or existing Quantum control systems.
Technical Specifications
| Specification | Detail |
|---|---|
| Product Type | Discrete Output Module |
| Output Channels | 16 independent channels |
| Output Voltage | 24 VDC nominal |
| Output Current | 0.5 A per channel, 4 A per common |
| Output Type | Positive logic (source) |
| Protection | Short circuit and overload |
| Isolation | 1500 V RMS field to logic |
| Response Time | 1 ms maximum |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | 130 x 40 x 115 mm |
| Weight | 0.4 kg |
| Backplane Current | 300 mA at 5 VDC |
| Terminal Type | Removable screw terminals |
| Status Indication | LED per channel |
| Compatibility | Modicon Quantum 140 series |
| Approvals | CE, UL, CSA, ATEX Zone 2 |
High-Density Output Design
The 140DDO15310C packs 16 independent channels into a compact 40 mm wide housing, maximizing I/O density in your panel. Each channel delivers 24 VDC at 0.5 A for typical industrial loads. Dedicated LED status indicators accelerate commissioning and troubleshooting.
Robust Protection Features
We equipped this module with short circuit and overload protection on each channel. This safeguards both the module and field devices from wiring faults. The protection automatically resets when the fault clears, eliminating manual intervention.
The module achieves 1 ms response time for time-critical applications. 1500 V RMS isolation prevents ground loops and transients from affecting control system operation.
Easy Integration
Measuring 130 x 40 x 115 mm and weighing 0.4 kg, this unit fits densely alongside other Quantum modules. Removable screw terminals accept 24-14 AWG wiring for error-free connections. For similar components, examine the RMS TSG TZ C Static Trip device.
With CE, UL, CSA, and ATEX Zone 2 approvals, the Schneider 140DDO15310C suits global industrial applications.
