The Schneider 140CRA93200 is a critical communication interface for scalable control systems. This RIO drop adaptor belongs to the renowned Schneider Electric Modicon Quantum series. It enables high-speed data exchange between the main processor and remote I/O expansion racks.
Enabling High-Speed, High-Capacity I/O Expansion
This module supports the connection of up to 27 individual I/O expansion modules. This capability provides immense flexibility for distributing control points throughout a facility. Furthermore, it utilizes a fast 1.544 Mbit/s coaxial cable link for responsive real-time data transmission.
Built for System Resilience and Reliability
The 140CRA93200 is built with features that enhance overall system resilience. It supports redundant cable configurations to maintain communication if a primary path fails. Moreover, its robust design operates reliably in industrial temperature ranges from 0°C to 60°C.
Complete Technical Specifications
| Feature | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Model / Part Number | 140CRA93200 |
| Product Line / Series | Modicon Quantum |
| Product Type | RIO (Remote I/O) Drop Adaptor |
| Maximum I/O Expansion | Supports up to 27 Modules |
| Communication Cable | 75 Ohm Coaxial |
| Transmission Rate | 1.544 Mbit/s |
| Connectors | 2 |
| Redundant Cable Support | Yes |
| Power Dissipation (2 ch) | 3.8W |
| Bus Current Requirement | 750 mA |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 95% Non-Condensing |
| Weight | 0.91 kg (2.00 lbs) |
| Mounting | Rack-Mountable (Standard Format) |
Designed for Demanding Industrial Environments
This adaptor is designed for the electrical and environmental demands of industrial automation. Its standard format ensures easy integration into existing Modicon Quantum racks. Therefore, the Schneider 140CRA93200 is a proven solution for extending and reinforcing your distributed control architecture.
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 55 × 180 × 260 mm |
