The Schneider 140CPS51100C delivers reliable and stable power for demanding industrial control systems. This module operates with an input voltage range of 100 to 240 Vac, ensuring global compatibility. It provides a robust output of 11 Amps at 5 Vdc for the backplane. The 140CPS51100C effectively converts AC line power to the DC voltages required by the rack. This ensures consistent performance for all connected modules in your automation architecture.
Technical Specifications and Physical Characteristics
Precise technical data is crucial for system design. The detailed specifications for the Schneider 140CPS51100C ensure seamless integration into existing setups.
| Specification | Details |
|---|---|
| Product Type | Power Supply Module (AC Input) |
| Series | Schneider Electric Modicon Quantum |
| Input Voltage | 100 to 240 Vac (Auto-ranging, 50/60 Hz) |
| Output Voltage | 5 Vdc for backplane / 24 Vdc for isolated output |
| Output Current | 11 Amps @ 5 Vdc / 400 mA @ 24 Vdc |
| Power Dissipation | 28 Watts Maximum |
| Width | 40 mm |
| Height | 140 mm |
| Depth | 115 mm |
| Weight | 0.85 kg |
| Connection Type | Detachable Screw Terminal Block |
| Protection Features | Short Circuit Protection, Overvoltage Protection |
| Hold-up Time | ≥10 ms (Energy storage capacitors) |
| Operating Temperature | 0°C to 60°C |
| LED Indicators | DC OK, Overvoltage |
Seamless Integration with Quantum Automation
The 140CPS51100C fits exclusively into the power supply slot of a Modicon Quantum rack. Its placement does not occupy any I/O module positions, maximizing the system’s capacity. This power supply ensures clean and regulated power distribution to all modules in the rack. It features LED indicators for quick visual confirmation of operational status and DC voltage output. This component represents a fundamental building block for reliable automation solutions, similar to protective units like the RMS TSG TZ C Static Trip device found in motor control centers. Proper power management ensures the integrity and longevity of the entire control system.
