The Schneider 140ARI03010 provides precise analog signal acquisition for the Modicon Quantum platform. This module offers eight differential input channels for flexible sensor connectivity. Consequently, engineers can integrate multiple process variables into a single, compact unit. The 140ARI03010 delivers reliable performance with a resolution of 13 bits for accurate data conversion.
Core Design for Signal Integrity
Schneider Electric designed this module with a high 10 MOhm input impedance. This feature minimizes signal loading and ensures measurement fidelity from field sensors. Furthermore, the differential input type effectively rejects common-mode noise in industrial environments. The standard Quantum format guarantees seamless mechanical and electrical integration.
Efficient System Integration and Power
The 140ARI03010 module requires only 200 mA from the Quantum backplane for operation. Its low power dissipation of just 1 Watt contributes to overall system efficiency. Additionally, the module requires nine input words in the controller’s I/O mapping table. This streamlined addressing simplifies configuration and programming efforts.
Detailed Technical Specifications
Below are the complete technical parameters for the Schneider 140ARI03010 analog input module.
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Product Model | 140ARI03010 |
| Product Line | Modicon Quantum |
| Module Type | Analog Input Module |
| Input Channels | 8 Differential |
| Input Resolution | 13 Bits |
| Input Impedance | 10 MOhm |
| Bus Current | 200 mA |
| Power Dissipation | 1 W |
| Frequency Range | 47 – 63 Hz |
| Addressing Requirement | 9 Input Words |
| Module Format | Standard Quantum |
| Weight | 2.00 lbs (0.91 kg) |
| Dimensions (Est.) | Standard Quantum Module (Refer to datasheet for exact HxWxD) |
Application Versatility and Performance
This Modicon Quantum module excels in applications requiring multiple isolated analog measurements. Typical uses include pressure, temperature, and flow monitoring in process control systems. The 47-63 Hz frequency range supports standard power line frequencies globally. Therefore, the 140ARI03010 is suitable for international industrial deployments.
Why Choose This Module?
Selecting the genuine Schneider 140ARI03010 ensures compatibility and long-term reliability. The module’s robust design withstands typical electrical noise found in factory settings. Its differential inputs provide superior noise immunity compared to single-ended designs. Ultimately, this module offers a trusted solution for high-quality analog data acquisition.
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 110 × 55 × 90 mm |
