This dual output module provides reliable DC switching capabilities for industrial control systems. Reliance Electric engineered this unit to handle demanding actuator and solenoid applications. Technicians will appreciate its robust output rating and straightforward installation.
Core Technical Specifications
The Reliance Electric 45C65 features two independent DC output channels for versatile control configurations. Its 2-amp per channel rating supports a wide range of industrial loads. The table below outlines the key technical parameters.
| Parameter | Specification |
|---|---|
| Module Type | DC Output Module |
| Output Channels | 2 independent outputs |
| Output Voltage | 115 VDC nominal |
| Maximum Voltage | 140 VDC |
| Output Current | 2 A per channel |
| Power Input | 5 VDC from backplane |
| Power Consumption | 6 W typical |
| Dimensions (W x H x D) | 4.2 x 5.5 x 2.8 inches |
| Weight | 1.3 lbs (0.59 kg) |
| Output Protection | Internal transient suppression |
| Component Count | Single main PCB with discrete output drivers |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -20°C to 70°C |
Mechanical Architecture and Component Layout
Engineers will find the internal architecture of this output module highly robust. The Reliance Electric 45C65 contains a single main circuit board with discrete output driver components. This design provides reliable switching for inductive loads like relays and solenoids. Additionally, the module includes built-in transient suppression that protects against voltage spikes. Operators can rely on consistent output performance even during frequent switching cycles.
Output Capabilities and System Integration
Furthermore, this module delivers two independent 115 VDC output channels for flexible control applications. Each channel handles up to 2 amps, supporting multiple devices per output. You can connect the unit to AutoMate I/O racks or distributed control networks. For static trip relay applications, this output module pairs seamlessly with modules like the RMS TSG TZ C Static Trip series. The 140 VDC maximum rating provides a comfortable safety margin for standard industrial power supplies.
Power Management and Environmental Durability
This module draws logic power directly from the AutoMate backplane. Its output circuits source power from external 115 VDC supplies for load switching. Moreover, the operating temperature range spans 0°C to 60°C, ensuring stable performance across diverse conditions. Reliance Electric (now part of ABB) designed this series for extended service life in demanding industrial applications. The compact footprint allows placement in standard I/O rack slots.
Details
| Weight | 3.6 kg |
|---|---|
| Dimensions | 280 × 150 × 80 mm |
