This processor module delivers advanced logic execution for AutoMate programmable control systems. Reliance Electric engineered this unit to handle complex automation tasks with 8K memory capacity. Technicians will appreciate its efficient processing and straightforward system integration.
Core Technical Specifications
The Reliance Electric 45C307B features a dedicated processor design optimized for industrial control applications. Its 8K memory capacity supports substantial ladder logic programs and data storage. The table below outlines the key technical parameters.
| Parameter | Specification |
|---|---|
| Module Type | PLC Processor Module |
| Series | AutoMate |
| Memory Capacity | 8K (8192 words) |
| Power Input | 5 VDC from backplane |
| Power Consumption | 8 W typical |
| Dimensions (W x H x D) | 4.2 x 5.5 x 2.8 inches |
| Weight | 1.4 lbs (0.64 kg) |
| Processor Type | Dedicated logic processor |
| Communication Interface | AutoMate network port, RS-232 programming port |
| Component Count | Single main PCB with memory backup circuitry |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -20°C to 70°C |
Memory Architecture and Processing Capabilities
Engineers will find the memory architecture of this processor module highly efficient. The Reliance Electric 45C307B utilizes 8K of dedicated memory for program storage and data handling. This capacity accommodates complex ladder logic routines for demanding automation sequences. Additionally, the module includes battery-backed memory that preserves programs during power interruptions. Operators can rely on consistent program retention without frequent reloading.
Mechanical Architecture and System Integration
Furthermore, this processor module installs directly into AutoMate rack systems. Its single-board design minimizes internal failure points while maximizing reliability. You can connect the unit to AutoMate I/O racks or distributed control networks. For static trip relay applications, this processor pairs seamlessly with modules like the RMS TSG TZ C Static Trip series. The RS-232 programming port supports straightforward ladder logic uploads and real-time system monitoring.
Power Management and Environmental Durability
This module draws power directly from the AutoMate backplane, eliminating separate wiring requirements. Its power regulation circuitry includes built-in transient suppression for industrial electrical environments. Moreover, the operating temperature range spans 0°C to 60°C, ensuring stable performance across diverse conditions. Reliance Electric (now part of ABB) designed this series for extended service life in demanding industrial applications.
Details
| Weight | 3.6 kg |
|---|---|
| Dimensions | 280 × 150 × 80 mm |
