Overview
The Phoenix Contact QUINT-PS/1AC/48DC/5 (2866679) is a compact, high-performance industrial power supply unit. It delivers a stable 48V DC output with a 5A current rating, supporting sensitive devices with robust protection features. Its advanced diagnostics and Power Boost function ensure dependable operation in demanding environments.
Key Features
- Provides 48V DC / 5A reliable output for industrial control equipment.
- Supports Power Boost up to 6.25A for 5 seconds during peak loads.
- Achieves >94% efficiency, reducing power loss and thermal stress.
- Accepts a wide 85–264V AC input range for global compatibility.
- Compact DIN rail housing saves space in control cabinets.
- Offers LED diagnostic indicators for real-time operational monitoring.
Technical Specifications
Input Data
| Parameter | Specification |
|---|---|
| Nominal Input Voltage | 100–240V AC |
| Voltage Range | 85–264V AC |
| Input Current | 1.1A at 230V / 2.2A at 120V |
| Frequency | 50 / 60 Hz |
| Inrush Current Limiting | Integrated |
Output Data
| Parameter | Specification |
|---|---|
| Output Voltage | 48V DC (adjustable 48–56V DC) |
| Output Current | 5A |
| Power Boost | 6.25A for 5 seconds |
| Efficiency | >94% |
Performance & Protection
| Parameter | Specification |
|---|---|
| Overvoltage Protection | Yes |
| Temperature Protection | Automatic shutdown |
| MTBF | >500,000 hours |
| Indicators | LED status and diagnostics |
| Protection Class | IP20 |
Environmental
| Parameter | Specification |
|---|---|
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Standards | IEC 60068 shock/vibration compliant |
Mechanical
| Parameter | Specification |
|---|---|
| Mounting | DIN Rail |
| Dimensions (H x W x D) | 130 x 63 x 125 mm |
| Weight | ~0.65 kg |
| Housing | Durable impact-resistant plastic |
Certifications
- CE, UL, IEC compliant
- EMC interference protection (IEC 61000-4-5)
Details
| Weight | 0.65 kg |
|---|
