The Pepperl+Fuchs NBB0,8-10GM35-E2-Y316479 inductive proximity sensor delivers precise and stable metal detection in compact automation setups. Its M10 nickel-plated brass housing ensures long-term durability even in harsh environments. With a sensing range of 0.8 mm and a PNP normally open output, it offers quick and accurate signal switching for various industrial control systems.
Key Features
- Reliable PNP NO output for efficient signal processing
- Compact M10 x 1 threaded housing for easy mounting
- Fast response with up to 5000 Hz switching frequency
- Robust design rated IP67 for complete dust and water resistance
- 2-meter PVC cable connection for flexible installation
- Non-flush design ideal for short-range, high-precision applications
Technical Specifications
| Parameter | Description |
|---|---|
| Sensing Range (Sn) | 0.8 mm |
| Output Type | PNP, Normally Open (NO) |
| Operating Voltage | 10–30 V DC |
| Switching Frequency | 0–5000 Hz |
| Housing Material | Nickel-plated Brass |
| Thread Size | M10 x 1 |
| Installation Type | Non-flush |
| Connection Type | 2 m PVC Cable |
| Protection Rating | IP67 |
| Operating Temperature | -25 °C to +70 °C |
Origin, Dimensions, and Weight
- Country of Origin: Germany
- Dimensions: M10 × 35 mm (diameter × length)
- Weight: Approx. 40 g
Application Insight
The NBB0,8-10GM35-E2-Y316479 performs best in metal detection, position feedback, and proximity measurement in compact automation systems. Its rugged IP67 design makes it ideal for factory automation, assembly machinery, and handling equipment where precision and reliability are critical.
Details
| Weight | 0.04 kg |
|---|---|
| Dimensions | 10 × 10 × 35 mm |
