The Honeywell 51153818-103 kit provides essential jumper components for system setup. This jumper kit belongs to the Honeywell accessory family for control modules. The kit enables flexible hardware configuration and signal routing adjustments. Each component allows technicians to modify electrical connections without soldering. Therefore, this kit simplifies field changes and maintenance procedures.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | 51153818-103 |
| Product Type | Jumper Kit |
| Number of Jumpers | 20 pieces per kit |
| Jumper Type | Shunt-style with insulation cover |
| Contact Material | Phosphor bronze with gold plating |
| Insulation Material | High-temperature thermoplastic |
| Current Rating | 2 A per contact |
| Voltage Rating | 50 VDC maximum |
| Contact Resistance | <20 mΩ |
| Pitch Spacing | 2.54 mm (standard) |
| Operating Temperature | -40°C to +105°C |
| Storage Temperature | -55°C to +125°C |
| Dimensions (box) | 120 x 80 x 15 mm |
| Weight (kit) | 0.05 kg |
| Country of Origin | USA |
Jumper Components and Construction
The 51153818-103 kit contains 20 individual jumper pieces for multiple configurations. Each jumper features a shunt-style design with an insulated cover for safety. Phosphor bronze contacts provide excellent conductivity and spring retention. Gold plating on the contacts resists corrosion for long-term reliability. The insulation material withstands high temperatures up to 105°C.
Electrical Ratings and Performance
This jumper kit supports a 2 A current rating per contact. The voltage rating reaches 50 VDC maximum for low-power applications. Contact resistance stays below 20 mΩ for minimal signal loss. The standard 2.54 mm pitch spacing matches most Honeywell control modules. Consequently, the Honeywell 51153818-103 works seamlessly with existing system hardware.
Physical Dimensions and Storage
The 51153818-103 kit comes in a compact storage box measuring 120 x 80 x 15 mm. Total kit weight reaches just 0.05 kg for easy handling. Operating temperature ranges from -40°C to +105°C for industrial use. Storage temperatures extend from -55°C to +125°C for warehouse conditions. Honeywell manufactures this jumper kit in the USA. Accordingly, users receive consistent quality for system maintenance.
Application and Usage
Technicians use these jumpers to enable or disable specific circuit paths. The kit supports hardware address selection on I/O modules. Jumpers also configure input range settings on analog cards. Therefore, the 51153818-103 kit serves as a vital maintenance accessory for control systems.
