Product Description
The GE IS220UCSAH1A is a high-performance UCSB controller module within the Mark VIe Control and Safety System family. It is designed to handle advanced control, protection, and communication tasks in critical industrial environments. Powered by a 600 MHz Intel EP80579 processor, the controller provides real-time response for demanding process applications.
Moreover, the IS220UCSAH1A supports multiple GE systems, including EX2100e excitation control and LS2100e static starter systems. Its robust hardware platform ensures long-term reliability in continuous operation and hazardous area installations.
Functional Highlights
This controller offers several innovative design features that simplify maintenance and integration:
- Fanless Design: Improves reliability and reduces maintenance costs by eliminating moving parts.
- Battery-Free Operation: Removes the need for periodic battery replacement, enhancing system uptime.
- Compact Single-Module Build: Ensures easy installation and efficient use of panel space.
- Software Compatibility: Shares nearly identical firmware and configuration tools with UCSC controllers, making system upgrades seamless.
- Industrial Durability: Built for use in ATEX Zone 2 and Class I, Division 2 environments, supporting Groups A, B, C, and D.
In addition, the UCSB controller supports redundant configurations and real-time communication across the GE Mark VIe control network.
Technical Specifications
| Parameter | Description |
|---|---|
| Manufacturer | General Electric (GE) |
| Model | IS220UCSAH1A |
| System Series | Mark VIe / EX2100e / LS2100e |
| Processor | Intel EP80579, 600 MHz |
| Nominal Input Voltage | 24V or 28V DC |
| Voltage Range | 18–30 VDC |
| Maximum Current Rating | 1.5 A DC |
| Operating Temperature | -30°C to +65°C (-22°F to +149°F) |
| Certifications | UL E207685, UL DEMKO 12 ATEX 1114875X |
| Hazardous Location Rating | ATEX Zone 2, Group IIC / Class I, Div 2 |
| Cooling Method | Convection (no fan) |
| Battery | None required |
| Mounting | Panel or rack-mountable |
Therefore, the IS220UCSAH1A offers dependable performance even under wide environmental variations and power fluctuations.
System Integration
The GE Mark VIe UCSB Controller integrates seamlessly into distributed control networks, supporting both simplex and redundant configurations. It communicates with I/O packs and Human-Machine Interfaces (HMIs) using GE’s proprietary control network protocols.
For instance, in gas turbine, steam turbine, or generator control applications, the IS220UCSAH1A ensures synchronized operations and high system integrity. Furthermore, it provides deterministic processing performance essential for real-time process safety and protection tasks.
Typical Applications:
- Gas and steam turbine control systems
- Power generation and excitation systems
- Industrial safety interlock systems
- Oil, gas, and petrochemical control solutions
Details
| Weight | 0.86 kg |
|---|
