Product Overview
The SC-UCMX01 51307195-175 Non-Redundant Controller from Honeywell delivers high-performance control for industrial automation. It supports 28 onboard I/O channels, dual-core ARM® Cortex™-A9 processing, and versatile communication through Ethernet, RS232, and RS485 ports. This controller accepts SD cards up to 32GB for data logging and performs reliably across a wide temperature range.
Key Features
- Handles 28 mixed I/O channels onboard for flexible signal acquisition
- Dual-core ARM® Cortex™-A9 CPU at 667 MHz ensures fast execution cycles
- Operates on 24 VDC input with 18–30 VDC range and 120 mVpp ripple
- Supports Ethernet protocols: TCP/IP, Modbus TCP, DNP3 TCP, and HART-IP
- RS232 distance up to 15 m, RS485 distance up to 1200 m (32 max slaves)
- Configurable datalog rate from 1 second up to 1 hour, 1 ms timestamp resolution
- CPU watchdog detects errors and automatically resets the processor
Technical Specifications
| Attribute | Details |
|---|---|
| Model | SC-UCMX01 |
| Order Number | 51307195-175 |
| Manufacturer | Honeywell |
| Category | Non-Redundant Controller |
| Input Voltage | 24 VDC ± 25% |
| Input Voltage Range | 18–30 VDC |
| Max Ripple Voltage | 120 mVpp |
| Max Input Current | 1.2 A at 30 VDC (controller + 9 IOMs) |
| Processor | Dual-core ARM® Cortex™-A9, 667 MHz |
| RAM | 128 MB |
| Flash Memory | 32 MB |
| Nonvolatile Memory | 4 Mbits, 20+ years data retention |
| Execution Cycle Time | ≥50 ms |
| SD Card Support | 32 GB Class 6/10 |
| Ethernet Ports | 2, 10/100BaseTx, auto-detecting |
| RS232 Ports | 2 |
| RS485 Ports | 2, up to 32 slaves, 1200 m max |
| Datalog Timestamp Resolution | 1 ms |
| Weight | 700 g |
| Dimensions | 190 x 99 x 141 mm |
| Mounting | DIN rail (TH35-7.5) |
| Operating Temperature | -40 to 75°C |
| Storage Temperature | -40 to 85°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Hazardous Location Approvals | FM, CSA, ATEX II 3 G, IECEx Ex nA IIC T4 Gc |
| CE Compliance | LVD, EMC |
| Flammability | UL 94 V-0 |
| Vibration | IEC 60068-2-6, 1.0 g (10–150 Hz) |
Model and Suffix Codes
| Code | Description |
|---|---|
| SC-UCMX01 | Non-redundant Controller with onboard 28 I/O |
Applications
- Industrial Automation: Controls sensors, actuators, and I/O in complex processes
- Data Logging: Supports high-resolution timestamps and SD card storage
- Redundant-Free Systems: Provides reliable performance for cost-effective setups
- Networked Operations: Integrates via Ethernet, RS232, and RS485 with Modbus or DNP3
Installation Notes
Mount the SC-UCMX01 51307195-175 on a DIN rail with proper ventilation. Ensure a stable 24 VDC power supply and correct grounding for RS485 communication over long distances.
FAQ
Q1: Are these controllers full original Honeywell products?
Yes, we supply brand-new, factory-original Honeywell controllers.
Q2: How quickly can I receive the controller?
We typically ship within 3 days to 2 weeks depending on order size.
Q3: Which logistics providers do you use?
We use DHL, FedEx, and other reliable couriers for worldwide shipping.
Q4: Can I return the product if it has defects?
Yes, returns are accepted within 30 days for quality-related issues.
Q5: What communication interfaces does the controller support?
The SC-UCMX01 51307195-175 supports Ethernet, RS232, RS485, Modbus TCP/RTU, DNP3 TCP, and HART-IP protocols.
