The Honeywell MU-TAIH23 functions as a field termination assembly within the Series T platform. Honeywell engineered this unit to provide reliable signal termination for analog I/O applications. It bridges field devices with control system processors effectively.
Technical Specifications
This field termination assembly features a compact design for efficient cabinet layout. The unit measures approximately 10.5 inches in width and 8.2 inches in height. It weighs around 1.2 kilograms, offering a sturdy build for industrial environments.
| Specification | Detail |
|---|---|
| Manufacturer | Honeywell |
| Model | MU-TAIH23 |
| Category | Field Termination Assembly |
| Series | Series T (TDC 3000) |
| Type | Analog I/O termination |
| Interface | Terminal block connections |
| Dimensions | 10.5 in x 8.2 in x 1.8 in (approx.) |
| Weight | 1.2 kg (approx.) |
| Mounting | Chassis or panel mount |
Signal Termination and Channel Organization
The Honeywell MU-TAIH23 organizes analog signals into clearly defined termination points. It accepts wiring from field sensors, transmitters, and actuators reliably. Each terminal provides secure clamping for consistent electrical contact. Consequently, this assembly reduces wiring errors and simplifies troubleshooting tasks.
Engineers can route signals efficiently using the logical terminal layout. The design follows standard Honeywell conventions for intuitive installation. Technicians benefit from the clear labeling on each connection point.
Integration with Series T Systems
This field termination assembly pairs directly with Honeywell Series T I/O boards. It supports the signal requirements of analog input and output channels. Installation involves mounting the assembly and terminating field wiring securely. The Honeywell MU-TAIH23 utilizes reliable screw-type terminals for long-term durability.
Furthermore, the assembly accommodates various wire gauges for installation flexibility. This adaptability reduces the need for additional terminal blocks or adapters. The design ensures signal integrity across all connected analog channels.
Construction and Installation Features
The housing incorporates durable materials suitable for industrial environments. Its robust construction withstands vibration and temperature variations commonly found in process plants. Mounting follows a straightforward procedure using standard chassis brackets. For similar industrial automation components
