Product Overview
The Honeywell MC-PDOY22 (Part No. 80363975-150) is a 32-point digital output processor designed for precise and reliable control in process automation systems. It belongs to the Experion and TDC3000 I/O family, offering seamless integration with standard 24 Vdc and 120/240 Vac field termination assemblies (FTAs). This module is conformally coated for enhanced durability in harsh industrial environments, ensuring long-term protection against moisture and contaminants.
Moreover, the MC-PDOY22 supports full galvanic isolation and high surge immunity, meeting ANSI/IEEE C37.90.1-1978 standards. It’s the ideal choice for users demanding high-density output control in critical plant operations.
Functional Highlights
- 32 Isolated Output Channels: Provides open-collector NPN transistor or relay output configuration options.
- Flexible Load Handling: Supports both 24 Vdc current-sinking and 120/240 Vac relay outputs.
- Galvanic Isolation: Optical coupler-based protection up to ±42.4 Vdc or 1500 Vac rms.
- Reliable Switching: Maximum load current up to 5 A per FTA, ensuring stable signal output.
- Fast Response Time: 200 ms (transistor type) or 10 ms (relay type) switching capability.
- Extended Service Life: Up to 10 million mechanical operations per relay output.
In addition, each module supports redundant operation and automatic failure detection, maintaining continuous process control even during hardware replacement.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | MC-PDOY22 (Coated) / MU-PDOY22 (Uncoated) |
| Output Channels | 32 |
| Output Type | NPN Open Collector / Relay Contact |
| Load Voltage Range | 15–30 Vdc (transistor) / 250 Vac or 125 Vdc (relay) |
| Load Current | 0.5 A max per point; 5 A total |
| Isolation Voltage | ±42.4 Vdc or 1500 Vac rms |
| Turn-On/Off Time | 200 ms (NPN) / 10 ms (Relay) |
| Fuse Protection | 1.6 A, 125 V fuse per group |
| Surge Withstand | ANSI/IEEE C37.90.1-1978 compliant |
| Redundancy | Supported via dual IOP architecture |
| Operating Voltage | +24 Vdc nominal |
| Mounting | Compatible with MU-TDOY and MU-KBFT bridge FTAs |
This configuration ensures safe operation under both resistive and inductive loads, making it suitable for control valves, solenoids, and motor contactors.
System Integration
The MC-PDOY22 easily integrates with Honeywell’s Experion PKS, C300, and TDC3000 systems. Its dual-FTA configuration allows users to expand outputs seamlessly from 16 to 32 circuits using MU-KBFT01/02 bridge cables. Furthermore, redundancy and diagnostic features enhance fault detection and simplify maintenance, ensuring consistent uptime across process control networks.
For instance, when combined with the MU-TDOY22 or MU-TDOY23 FTAs, the module provides a compact, high-density interface supporting both DC and AC field devices without external adapters.
Details
| Weight | 0.58 kg |
|---|
