The Honeywell MC-PC1X02 delivers exceptional accuracy for measuring non-corrosive gas pressures. This premium differential pressure transducer maintains remarkable long-term stability in demanding environments. Consequently, it provides reliable data for critical process control and monitoring applications.
Core Measurement Performance and Design
This transducer achieves an outstanding accuracy of ±0.05% of its full scale. Moreover, it guarantees a long-term stability of ±0.1% of full scale per year. Therefore, it minimizes measurement drift and reduces the need for frequent recalibration. The robust Polyphenylene Sulfide (PPS) housing ensures durability against harsh industrial conditions.
Detailed Technical Specifications
The table below provides the complete electrical, mechanical, and performance specifications.
| Parameter | Specification |
|---|---|
| Manufacturer | Honeywell |
| Model Number | MC-PC1X02 |
| Product Type | Differential Pressure Transducer |
| Measured Media | Non-Corrosive Gases |
| Pressure Range | ±125 psi (±18.62 kPa) |
| Reference Accuracy | ±0.05% of Full Scale (Best Straight Line) |
| Long-Term Stability | ±0.1% of Full Scale per year |
| Output Signal | 4-20 mA (2-wire) |
| Supply Voltage Range | 12-30 V DC |
| Power Consumption | 5 mA (Typical, without load) |
| Operating Temperature | -20°C to +60°C |
| Housing Material | Polyphenylene Sulfide (PPS) |
| Process Connection | 1/4 inch NPT (Female) |
| Electrical Connection | 1/2 inch NPT Conduit |
| Enclosure Protection Rating | IP66 |
| Response Time | < 10 ms (Typical, 10% to 90%) |
| Warm-Up Time | < 2 seconds to rated performance |
| Weight | Approx. 0.45 kg (1 lb) |
| Mounting Orientation | Any (Performance not affected) |
Installation and Integration Features
The MC-PC1X02 features a compact and rugged design for easy installation. Furthermore, its standard 1/4-inch NPT process connections simplify integration into existing piping. The IP66-rated enclosure provides reliable protection against dust and water jets. This transducer is ideal for HVAC systems, cleanroom monitoring, and filter status checks. For system-wide protection, it can be integrated into networks alongside devices like the RMS-TSG-TZ-C Static Trip.
Details
| Weight | 0.3 kg |
|---|---|
| Dimensions | 30 × 313 × 278 mm |
