Product Description

The Honeywell LG1093AA24 is a rugged UV flame sensor built for gas turbines and industrial combustion systems. With fast flame detection, wide temperature tolerance, and global certifications, it’s trusted in critical energy sectors including offshore and power generation.

Key Features

• High-speed response — Flame detection in just 0.1 seconds
• Flexible power options — Supports 28 VDC, 20–35 VDC, or 115 VAC
• Long-distance installation — Operates reliably up to 1000 ft from amplifier
• ATEX & CE Certified — Safe for hazardous and explosive environments
• Proven performance — Over 35 years of success in GE turbine platforms

Technical Specifications

• Model: LG1093AA24
• Mounting: 3/4-inch internal NPT
• Connection: Teflon-shielded cable with 1″ external conduit thread
• Window Pressure Rating: Up to 150 psig @ 400°F
• Operating Temp: -40°F to +350°F (-40°C to +177°C)
• Certifications: CE (EMC, LVD), ATEX 94/9/EC, Factory Mutual (explosive atmospheres)

Available Cable Lengths

• AAx4: 16 ft (4.9 m)
• AAx5: 42 ft (12.8 m)
• AAx6: 61 ft (18.6 m)

Applications

• Gas turbines in land-based and offshore facilities
• Industrial plants and process burners
• Shipboard and remote energy generation systems
