Product Overview
The Honeywell FTA-T-02 is a fail-safe digital output Field Termination Assembly (FTA) designed to deliver secure and reliable signal transmission in industrial automation systems. Built for precision and safety, it provides 24 output channels grouped into six isolated sets, ensuring stable and fault-tolerant control performance.
Moreover, its robust design and compliance with CE and UL standards make it suitable for demanding industrial environments where safety and long-term reliability are critical.
Functional Highlights
- Fail-Safe Design – Ensures automatic transition to a safe state in the event of signal failure or power loss.
- 24 Isolated Channels – Organized into six groups of four for simplified wiring and improved channel protection.
- Wide Voltage Range – Supports 24 VDC, 48 VDC, and 60 VDC systems for maximum flexibility in different plant architectures.
- Industrial Compliance – Meets IEC 1010 (1990) standards for overvoltage categories 2 and 3, providing superior electrical safety.
- Easy Integration – Compact DIN rail mounting compatible with TS32 and TS35 x 7.5 rails ensures quick installation and space efficiency.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Honeywell |
| Model Number | FTA-T-02 |
| Product Type | Fail-Safe Digital Output FTA |
| Number of Channels | 24 (6 groups of 4) |
| Operating Voltage | 24 / 48 / 60 VDC |
| Max Voltage Rating | 36 Vac / 50 Vdc (OV Cat 3); 125 Vac / 150 Vdc (OV Cat 2) |
| Max Continuous Current (per channel) | 2 A |
| Approvals | CE, UL |
| Terminal Type | Screw terminals |
| Max Wire Diameter | 0.25 cm² (AWG 14) |
| Strip Length | 0.7 cm (0.28 in) |
| Tightening Torque | 0.5 Nm (0.37 ft-lb) |
| Dimensions (L × W × H) | 14.5 × 7 × 5.7 cm |
| DIN Rail Compatibility | TS32 / TS35 × 7.5 |
| Used Rail Length | 14.6 cm (5.75 in) |
| Shipping Weight | 2 kg |
System Integration
The FTA-T-02 module integrates seamlessly with Honeywell process control systems, offering efficient signal interfacing for safety-critical and automation control applications.
It is ideal for use in distributed control systems (DCS), emergency shutdown (ESD) units, and fail-safe PLC architectures where reliability and redundancy are essential.
In addition, the compact DIN-mounted design allows engineers to simplify panel wiring and reduce installation time while maintaining high operational safety.
Details
| Weight | 0.44 kg |
|---|---|
| Dimensions | 178 × 356 × 368 mm |
