Overview
The DC-TDIL01 (51307780-176) is a 24V digital input IOTA module designed for non-redundant operation. It integrates seamlessly into HONEYWELL Series C systems and interfaces with DI-24 / DI-SOE OM block types. This module delivers reliable digital input control for industrial automation applications.
Key Features
- Non-Redundant Design: Optimized for single-path digital input applications.
- Seamless Series C Integration: Works directly with HONEYWELL DI-24 / DI-SOE OM blocks.
- Compact Digital Input Solution: Reduces footprint while maintaining robust performance.
- Accessible Spare Parts: Supports terminal plug-in assemblies, fuses, and module-specific components.
- Reliable IOTA Interface: Ensures accurate signal transmission within Series C systems.
Technical Specifications
| Parameter | Specification |
|---|---|
| IOTA Model Number | DC-TDIL01 |
| HONEYWELL Part Number | 51307780-176 |
| Description | Digital Input 24V IOTA (Non-Redundant) |
| Supported OM Block Types | DI-24 / DI-SOE |
| IOM Model Number | DC-PDIL51 |
| IOTA Supported FTAs / Ancillary Cards | None |
| Input Voltage | 24 VDC |
| Module Type | Digital Input |
| Redundancy | Non-redundant |
| Spare Parts | Terminal plug-in assembly, fuses, module components |
Applications and Integration
The DC-TDIL01 51307780-176 is suitable for industrial control systems requiring accurate digital input processing. It ensures stable operation, seamless Series C integration, and easy maintenance using accessible spare parts.
Installation and Maintenance
The DC-TDIL01 51307780-176 installs efficiently into Series C racks. Plug-in terminals provide clear labeling for each channel. Maintenance involves straightforward replacement of fuses or the module itself, minimizing system downtime.
Details
| Weight | 0.4 kg |
|---|
