The Honeywell CC-TDOB01 delivers reliable and high-density control for industrial automation systems. This 32-channel Digital Output Module integrates directly with the Honeywell Experion Series C I/O backplane. Consequently, it provides a seamless and unified platform for managing critical field devices. Operators primarily use it to command actuators, solenoid valves, and motor starters with precision.
Detailed Technical Specifications and Design
Engineers value this module for its compact, DIN-rail mountable design that saves panel space. Specifically, each of its 32 channels employs a Form C (SPDT) dry contact relay output. This configuration offers maximum wiring flexibility for various load types. Moreover, the channels deliver a nominal 24VDC signal and support a robust 0.5A maximum current per point. For enhanced system safety, a 1500V isolation barrier separates all channels from the internal power supply.
Below is a comprehensive summary of the module’s core technical parameters.
| Specification Category | Detailed Parameter |
|---|---|
| Manufacturer & Model | Honeywell CC-TDOB01 |
| Module Type | Digital Output Module (DOM) with Backplane |
| Compatible System | Honeywell Experion Series C I/O |
| Number of Channels | 32 Isolated Outputs |
| Output Type | Form C Dry Contact (SPDT Relay) |
| Output Voltage | 24 VDC Nominal |
| Output Current | 0.5 A Maximum per Channel |
| Isolation Rating | 1500 V between Channels & Power Supply |
| Mounting Style | DIN Rail |
| Primary Function | High-Density Discrete Device Control |
Key Application Benefits
System integrators select the Honeywell CC-TDOB01 to streamline complex control architectures. Its high channel count consolidates numerous control points into a single, efficient module. Therefore, it is ideal for applications in process control, packaging machinery, and material handling systems. Furthermore, its native integration with the Experion ecosystem guarantees simplified configuration and powerful diagnostic capabilities.
Details
| Weight | 0.68 kg |
|---|---|
| Dimensions | 145 × 100 × 40 mm |
