The Honeywell CC-TAIX01 (51308363-175) is a high-level analog input module for Experion Series C systems. It accepts voltage or current signals from field transmitters and sensors. This module provides eight individually configurable input channels for maximum application flexibility. The CC-TAIX01 converts analog signals to digital values with high precision and accuracy.
Technical Specifications
| Specification | Details |
|---|---|
| Product Type | Analog Input Module |
| Part Number | CC-TAIX01 (51308363-175) |
| Series | Honeywell Experion Series C |
| Input Channels | 8 Differential or 16 Single-Ended |
| Voltage Ranges | ±10V, 0-10V, ±5V, 0-5V, ±1V, 0-1V |
| Current Ranges | 0-20mA, 4-20mA |
| Resolution | 16 Bits |
| Accuracy | ±0.05% of Full Scale |
| Update Rate | 100 ms for All Channels |
| Isolation | 500 Vdc Channel-to-Channel |
| Module Width | 40 mm (Single Slot) |
| Height | 230 mm |
| Depth | 150 mm |
| Weight | 0.85 kg |
| Power Consumption | 5W Maximum |
| Operating Temperature | 0°C to 60°C |
Key Features
The CC-TAIX01 offers exceptional flexibility through per-channel input type configuration. Sixteen-bit resolution delivers precise measurement of process variables with 65,536 distinct values. Common mode rejection exceeds 100 dB for excellent noise immunity in industrial environments. Galvanic isolation protects the control system from field transients and ground loops. Engineers use this module for pressure, temperature, flow, and level monitoring applications. Each channel connects directly to two-wire 4-20mA transmitters without additional power supplies. The module integrates seamlessly into Honeywell Experion Series C I/O racks. Status LEDs indicate module health and channel activity for quick troubleshooting. Similar to protection devices like the RMS TSG TZ C Static Trip unit, this module ensures reliable signal acquisition.
