Optimized for High-Channel, Low-Level Signal Acquisition
The Honeywell CC-TAIM01 51305959-175 multiplexer module delivers superior signal acquisition density. This module interfaces seamlessly with a wide variety of sensors and transducers. It provides sixty-four fully isolated analog inputs for comprehensive process monitoring. Consequently, it is a core component within the robust Honeywell IOTA Series platform.
Core Technical Specifications and Physical Profile
This CC-TAIM01 module is engineered for reliable performance in control systems. Its compact design maximizes channel density while ensuring industrial durability. Furthermore, the module’s complete isolation guarantees signal integrity across all sixty-four channels.
Detailed Technical Parameters
| Parameter | Specification |
|---|---|
| Manufacturer | Honeywell |
| Full Model Number | CC-TAIM01 51305959-175 |
| Product Series | IOTA Series / Series C Platform |
| Product Category | Low-Level Analog Input Multiplexer (MUX) Module |
| Number of Channels | 64 Fully Isolated Analog Inputs |
| Isolation Specification | Channel-to-Channel & Channel-to-System |
| Maximum Scan Rate | Up to 64 channels per second |
| Module Dimensions (H x W x D) | 3.0 cm x 31.3 cm x 27.8 cm |
| Module Weight | 0.56 kg |
| Typical Power Consumption | 5 Watts (System dependent) |
| Electrical Interface | High-density backplane connector |
| Operating Temperature Range | 0°C to 60°C (Standard for IOTA series) |
| Input Signal Type | Low-Level Analog (mV/V, thermocouple, RTD) |
| Country of Origin | United States of America (USA) |
| Warranty Period | 12 Months |
| Condition | Brand New, Factory Fresh |
| Primary Compliance | Designed for industrial process control standards |
Key Features and System Integration Benefits
This multiplexer offers significant advantages for system designers and integrators. Its high channel density drastically reduces cabinet space and hardware costs. The fast scan rate supports real-time data acquisition for responsive control loops. Moreover, the robust channel isolation prevents ground loops and eliminates signal crosstalk. The module integrates directly with Honeywell’s IOTA and Series C control architectures.
Application Use Cases and Operational Reliability
The CC-TAIM01 51305959-175 is ideal for data-intensive monitoring applications. It commonly acquires signals from thermocouples, RTDs, and strain gauges in process plants. The module performs reliably in harsh environments with electrical noise and temperature variations. Its design ensures continuous operation for critical process monitoring and safety systems. Therefore, it is a trusted solution for chemical, pharmaceutical, and power generation industries.
Installation and Compatibility Notes
Installation requires mounting the module in a compatible Honeywell IOTA chassis. Technicians must configure the channel scanning and signal conditioning via system software. All sixty-four channels utilize the module’s integrated isolation barriers by default. Furthermore, proper cabling and shielding practices are essential for optimal low-level signal performance.
Details
| Weight | 0.68 kg |
|---|---|
| Dimensions | 145 × 100 × 40 mm |
