The CC-SDOR01 from Honeywell serves as a dedicated digital output relay module for industrial control systems. This unit provides isolated switching capabilities for field devices requiring contact closure control. Its relay outputs handle various load types including solenoids, contactors, alarms, and indicator lamps. Consequently, automation applications achieve reliable control of AC or DC powered devices without additional interface components.
Weighing approximately 0.88 lbs (0.40 kg), the CC-SDOR01 features a compact industrial enclosure suitable for mounting in Honeywell control system racks. The module contains multiple relay output channels with isolated contacts for each independent circuit. Each relay provides both normally open and normally closed contacts, offering flexibility for different control logic requirements. Additionally, the unit incorporates status indication for each output channel to verify operation at a glance.
Comprehensive Relay Output Capabilities
The CC-SDOR01 delivers reliable switching for diverse field devices including motor starters, pilot lights, solenoids, and audible alarms. Its relay contacts handle both AC and DC loads up to their rated voltage and current specifications without performance degradation. Each output channel includes transient suppression to protect contacts from inductive load switching arcs. This protection significantly extends relay life while reducing electrical noise in the control system.
Advanced Diagnostic and Status Features
This digital output module provides individual LED indicators for each relay channel, displaying output state for immediate visual verification during operation. Built-in coil monitoring detects open-circuit or short-circuit conditions on relay coils, reporting faults to the control system. The module communicates detailed channel status and diagnostic information for comprehensive system monitoring. These diagnostic features enable maintenance personnel to quickly identify output circuit issues without external test equipment.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Honeywell |
| Product Type | Digital Output Relay Module |
| Product Line | Series |
| Part Number | CC-SDOR01 |
| Weight | 0.88 lbs (0.40 kg) approximately |
| Output Type | Relay contacts |
| Contact Configuration | Normally open and normally closed per channel |
| Load Types | AC and DC |
| Applications | Solenoids, Contactors, Alarms, Indicators |
| Contact Protection | Transient suppression |
| Status Indication | LED per channel |
| Coil Monitoring | Open-circuit and short-circuit detection |
| Mounting Type | Honeywell control system rack |
| Operating Temperature | Industrial range |
