Product Overview
The Honeywell CC-PWRR01 Redundant Power Supply Module is designed for the Series C power system, providing 24 Vdc power to compatible Series C components. With its redundant power supplies and optional battery backup, this module ensures reliable and continuous power, making it ideal for critical applications where uninterrupted operation is essential. Its modular “Blade” design allows for easy field maintenance and enhanced reliability.
Key Features
- Modular Blade Design: Easy field maintenance and space-efficient design for seamless integration.
- Redundant Power Supply: Ensures continuous power availability.
- Optional Battery Backup: Provides up to 30 minutes of backup power at 20A (available only in the 20A system).
- Seamless Power Switching: Smooth transitions between power supplies and battery backup.
- Visual and Point Contact Alarms: Alerts for all power system components.
- HAZLOC Approvals: Full Series-C HAZLOC approvals for hazardous locations.
Detailed Specifications
| Feature | Specification |
|---|---|
| AC Input (VAC, rms) | 100-230V (Operating Band) / 85-264V (Operating Limits) |
| Frequency (Hz) | 47-63 Hz |
| Holdup Time | 20 ms |
| Output Voltage (VDC) | 24-26 VDC |
| Battery Backup (UPS) | 30 minutes at 20A max (20A system only) |
| Output Current | 20A System: 0-20A, 40A System: 0-40A |
| Efficiency | 65% minimum |
| Input Current @ 120/240 VAC Line | Inrush/Rerush: 35A peak, Running: 5.5A @ 120V, 2.7A @ 240V |
| Power Factor | 0.95 minimum |
| Ambient Temperature | 0 to 60°C |
| Max Rate of Change | 0.25°C/min for 20A, 1°C/min for 40A |
Additional Notes
- Battery Backup is available only with the 20A Power System.
- The 40A Power System requires three AC mains power feeds for operation.
Model Numbers
- Model: CC-PWRR01
- Part Number: 51198685-100
- Spare/Loose Items: 20A Power Supply
Details
| Weight | 0.8 kg |
|---|
