The Honeywell 900RTS-0001 functions as a Remote Terminal Panel for distributed I/O applications in industrial automation. This unit provides field termination and signal conditioning for remote locations away from the main control cabinet. You can deploy this panel to reduce wiring costs and simplify field device connections.
Technical Specifications
| Specification | Detail |
|---|---|
| Product Type | Remote Terminal Panel (RTP) |
| Compatible Systems | Honeywell Series 900 and Experion control platforms |
| I/O Capacity | Up to 32 field devices |
| Termination Points | 64 screw terminals |
| Terminal Type | Pluggable spring-clamp, 14-22 AWG |
| Signal Types | Digital I/O, analog I/O, thermocouple, RTD |
| Communication Interface | PROFIBUS DP, DeviceNet, or MODBUS RTU |
| Communication Speed | Up to 12 Mbps (PROFIBUS) |
| Power Supply | 24 VDC ±20% |
| Power Consumption | 8 W typical (with I/O modules) |
| Dimensions (H x W x D) | 350 mm x 300 mm x 120 mm |
| Weight | 4.5 kg (9.92 lbs) |
| Enclosure Material | Powder-coated steel, IP65 rating |
| Mounting | Wall or machine mount |
| Cable Entries | 6 x M20 threaded entries (top and bottom) |
| LED Indication | Power, communication status, I/O module status |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Approvals | CE, UL, CSA, ATEX Zone 2, IECEx |
Distributed I/O Architecture
The 900RTS-0001 enables distributed control by positioning I/O closer to field devices. This approach significantly reduces long cable runs from sensors and actuators. You therefore minimize installation costs and simplify troubleshooting throughout the facility.
The panel accommodates up to 32 field devices through 64 screw terminals. Each terminal accepts 14-22 AWG wiring with pluggable spring-clamp connections for easy maintenance. You can remove and replace terminal blocks without disturbing field wiring.
Flexible Communication Options
We equipped this remote terminal panel with multiple fieldbus options for system integration. PROFIBUS DP provides high-speed communication up to 12 Mbps for time-critical applications. DeviceNet and MODBUS RTU alternatives ensure compatibility with existing networks.
The panel communicates seamlessly with Honeywell Series 900 and Experion control platforms. LED indicators display power status, communication activity, and I/O module health at a glance.
Rugged Enclosure Design
The Honeywell 900RTS-0001 features a powder-coated steel enclosure with IP65 rating. This robust construction withstands washdown environments, dust, and moisture. You can therefore install the panel directly on machinery or in harsh process areas.
6 x M20 threaded cable entries at top and bottom accommodate field wiring. The entries accept standard industrial cable glands for secure sealing. Internal grounding terminals provide equipotential bonding for electrical safety.
Environmental Durability
This remote terminal panel operates reliably in -20°C to +60°C environments, suitable for most industrial facilities. The -40°C to +85°C storage range allows safe transport and inventory management. 5% to 95% non-condensing humidity tolerance ensures dependable performance in varying conditions.
ATEX Zone 2 and IECEx approvals permit installation in hazardous areas with occasional explosive atmospheres. For similar industrial automation components, examine the RMS TSG TZ C Static Trip protection device available through equipment suppliers.
Simplified Installation and Maintenance
Measuring 350 mm x 300 mm x 120 mm and weighing 4.5 kg, the 900RTS-0001 mounts easily on walls or machine frames. Pre-drilled mounting holes accept standard fasteners for secure attachment. The hinged cover provides access to terminals while protecting electronics when closed.
With CE, UL, CSA, ATEX Zone 2, and IECEx approvals, this remote terminal panel meets global standards for industrial automation equipment. Applications include material handling, packaging lines, process skids, and remote equipment monitoring.
