The Honeywell 900RTC-H010 functions as a precision Real-Time Clock (RTC) module within the Honeywell TPN series of industrial automation products. This unit provides accurate timekeeping for TPN controllers and other devices, ensuring synchronized operations. Consequently, it maintains correct time even during power outages through its integrated battery backup.
Core Technical Specifications
We engineered the Honeywell 900RTC-H010 for reliable timekeeping in demanding industrial environments where precise event timing is critical. The table below details its essential physical and electronic parameters:
| Parameter | Specification |
|---|---|
| Manufacturer | Honeywell |
| Model Number | 900RTC-H010 |
| Product Type | Real-Time Clock (RTC) Module |
| Series | TPN Series Industrial Automation Products |
| Power Requirements | 24 VDC |
| Communication Interface | RS-232 |
| Memory | SRAM |
| Operating Temperature | 20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% (non-condensing) |
| Dimensions (W x H x D) | 90 mm x 58 mm x 30 mm |
| Weight | 195 g (0.43 lb) |
Key Features
| Feature | Description |
|---|---|
| Accurate Timekeeping | Provides precise time for TPN controllers and devices |
| Battery Backup | Maintains time accuracy during power loss |
| Multiple Time Formats | Configurable for GMT, UTC, and local time |
| Network Synchronization | Can sync with a network time server |
| Event Timestamping | Generates timestamps for system events |
Precision Timekeeping with Battery Backup
The 900RTC-H010 maintains accurate time even when the main system power is completely lost. Its internal battery automatically takes over, preserving the clock and SRAM contents indefinitely. Therefore, you never need to manually reset the time after power interruptions.
Flexible Time Format Configuration
You can configure this module to output time in various formats including GMT, UTC, and local time. This flexibility ensures compatibility with global operations and different system requirements. As a result, the Honeywell 900RTC-H010 adapts to your specific timekeeping needs.
Network Time Server Synchronization
The module supports synchronization with external network time servers for ultimate accuracy. It can regularly update its time to match highly precise reference clocks. Consequently, multiple controllers across your plant can maintain perfectly synchronized time stamps.
Event Timestamping for Critical Operations
With its accurate timekeeping, the 900RTC-H010 generates precise timestamps for system events and alarms. Operators can rely on these timestamps for sequence-of-events analysis and troubleshooting. Hence, it supports root cause analysis during incident investigations.
RS-232 Communication Interface
An industry-standard RS-232 interface allows easy connection to TPN controllers and other devices. This serial connection provides reliable communication for time synchronization and data exchange. Therefore, integration into existing TPN series systems is straightforward.
SRAM Memory for Data Retention
Built-in SRAM provides temporary storage for time-related data and configuration parameters. The battery backup ensures this memory retains its contents during power loss. As a result, all settings remain intact when the system restarts.
Compact Form Factor for Easy Installation
Measuring just 90 mm x 58 mm x 30 mm, this module occupies minimal space within your control cabinet. Its compact size allows installation in tight spaces alongside other TPN series components. Weighing only 195 grams, it adds negligible weight to your system.
Wide Environmental Tolerance
The Honeywell 900RTC-H010 operates reliably in temperatures from 20°C to +60°C. It withstands storage extremes from -40°C to +85°C and humidity levels up to 95% non-condensing. Consequently, you can deploy it in diverse industrial environments without special protection.
Details
| Weight | 0.2 kg |
|---|---|
| Dimensions | 85 × 65 × 30 mm |
