The Honeywell 900H32-0001 functions as a heavy-duty 32-channel digital output module for Honeywell HC900 and ControlEdge HC900 controllers. This unit provides high-side current-sourcing outputs with advanced galvanic isolation for demanding industrial applications. Consequently, it ensures reliable and safe digital control of solenoids, actuators, and indicators in process automation systems.

Core Technical Specifications

We engineered the Honeywell 900H32-0001 with robust isolation and overload protection for maximum reliability in harsh environments. The table below details its essential physical and electronic parameters:

High-Density 32-Channel Output Architecture

This module provides 32 independent digital output channels in a single, compact unit for the HC900 platform. You can directly control a wide array of field devices without requiring external interposing relays. Therefore, the Honeywell 900H32-0001 significantly increases I/O density while reducing cabinet wiring complexity.

Advanced Galvanic Isolation for Noise Immunity

The module features galvanic isolation divided into two groups of 16 channels each. This design prevents electrical noise and ground loops from propagating between different sections of field wiring. Consequently, it maintains signal integrity even in electrically harsh industrial environments.

Wide Operating Voltage Range

The 900H32-0001 accepts a broad input voltage range from 10.5 to 32 V DC, accommodating various field power supplies. This flexibility allows integration into systems with different voltage standards without additional components. As a result, you can standardize on this module across multiple applications.

Fast 6 ms Switching for Time-Critical Control

Each output channel provides fast 6 ms switching times, suitable for applications requiring rapid response. This speed enables precise control of fast-acting solenoids, indicators, and interlocking circuits. Hence, the module supports both process control and high-speed discrete automation tasks.

Integrated Overload Protection for System Safety

Built-in overload protection on every output channel safeguards the module and field wiring from fault conditions. If a short circuit or overcurrent occurs, the protection activates immediately to prevent damage. Therefore, the Honeywell 900H32-0001 enhances overall system reliability and reduces maintenance.

Seamless HC900 and ControlEdge Integration

You can install this module directly into HC900 or ControlEdge HC900 I/O racks alongside other modules. It communicates with the controller via the backplane, automatically mapping outputs for easy programming. Consequently, engineers can configure and monitor all 32 channels using standard Honeywell engineering tools.

Robust Construction for Demanding Applications

Honeywell designed this output module for long-term reliability in heavy industrial environments. Its rugged construction withstands vibration, temperature extremes, and electrical noise common in process plants. As a result, you can deploy the 900H32-0001 in the most demanding automation setups.

Versatile Application Suitability

The Honeywell 900H32-0001 excels in a wide range of industrial automation applications. It provides reliable output control in process control systems, DCS architectures, and manufacturing execution systems. Therefore, it serves as a versatile building block for scalable automation solutions.
