Enabling Seamless Fieldbus Communication for Control Systems
The Honeywell 8C-IP0101 51454362-175 is a robust PROFIBUS DP gateway assembly. This coated version provides enhanced durability and environmental protection for industrial networks. It ensures reliable, high-speed data exchange between control systems and field devices. Consequently, this gateway is optimized for integration within Honeywell Experion PKS architectures.
Technical Specifications and Physical Design
This gateway assembly from Honeywell facilitates the industry-standard PROFIBUS DP protocol. Its design includes a protective coating for resistance to harsh industrial environments. Furthermore, the compact form factor allows for straightforward DIN rail mounting in control cabinets.
Detailed Technical Parameters
| Parameter | Specification |
|---|---|
| Manufacturer | Honeywell |
| Full Model Number | 8C-IP0101 51454362-175 |
| Product Type | PROFIBUS DP Gateway / Communication Interface Assembly |
| Primary Protocol | PROFIBUS DP (Decentralized Periphery) |
| Supported Network | PROFIBUS-DP (Master/Slave functionality) |
| Data Transmission Speed | Up to 12 Mbps (Configurable: 9.6 kbps to 12 Mbps) |
| Electrical Interface | RS-485 (for PROFIBUS DP network) |
| Host System Interface | Proprietary bus connection to Experion hardware |
| Power Supply Requirement | 24 VDC (Typical for I/O modules) |
| Typical Power Consumption | 5 Watts (System dependent) |
| Operating Temperature Range | 0°C to 60°C (Standard industrial) |
| Protective Coating | Yes, for enhanced environmental resistance |
| Mounting Method | Standard 35 mm DIN Rail |
| Module Dimensions (H x W x D) | Approx. 120 mm x 80 mm x 60 mm |
| Module Weight | Approximately 0.35 kg |
| Status Indicators | LEDs for Power, Network Status, Data Activity |
| Maximum Number of Devices | Supports up to 125 PROFIBUS slaves (theoretical max, system limited) |
| Isolation | Galvanic isolation between system and fieldbus side |
| Certifications | Designed for industrial EMI/RFI environments, PROFIBUS conformance |
Key Features and Integration Benefits
This gateway enables seamless connection of PROFIBUS DP networks to Experion PKS. Its protective coating safeguards internal electronics from dust, moisture, and chemical exposure. The assembly supports high-speed cyclic data exchange for real-time control applications. Moreover, its DIN-rail mounting and clear LED indicators simplify installation and troubleshooting. This makes the 8C-IP0101 a critical link for integrating third-party devices.
Application Context and System Role
The gateway acts as a master or slave device on the PROFIBUS DP network segment. It interfaces with remote I/O stations, variable frequency drives, and other smart field instruments. The 8C-IP0101 51454362-175 is essential for modernizing or expanding existing plant control systems. Its reliable performance ensures continuous communication in demanding settings like oil & gas or manufacturing. Therefore, it is a key component for achieving integrated and interoperable automation.
Installation and Configuration Notes
Installation requires mounting the module on a DIN rail within a suitable enclosure. Technicians must connect the PROFIBUS network using shielded, twisted-pair cable with proper termination. Configuration of the bus parameters and device mapping occurs within the Experion PKS engineering software. Furthermore, proper grounding of the shield is crucial for network stability and noise immunity.
