Industrial automation systems need powerful and stable processing. The Honeywell 620-1030 delivers robust logic execution for control applications. This module functions as a processor unit from Honeywell. It serves as the central brain for various industrial systems.
Technical Specifications & Dimensions
This processor handles complex logic and data management tasks efficiently. The table below outlines its core technical parameters.
| Parameter | Specification |
|---|---|
| Processor Type | 32-bit microprocessor |
| Clock Speed | 50 MHz |
| User Program Memory | 512 KB |
| Data Memory | 128 KB |
| Scan Rate | 0.5 ms per 1K of logic |
| Communication Ports | 1 x RS-232, 1 x RS-485 |
| Battery Backup | Lithium coin cell (user replaceable) |
| Power Supply | 5V DC from backplane |
| Current Consumption | 450 mA typical |
| Unit Weight | 0.52 kg (1.15 lbs) |
| Dimensions (WxHxD) | 40 x 120 x 140 mm |
| Number of Components | 1 CPU board + 1 power regulator board |
Construction and Interface Layout
This module features a rugged metal housing with EMI shielding. Such a design protects the processor from industrial electrical noise. Furthermore, the Honeywell 620-1030 provides front-accessible ports for communication. You will find two serial connectors and a programming port on the faceplate. The module includes a battery access door on the top side. LED indicators show power, run, and fault status clearly.
Energy Storage and Data Retention
Unlike basic logic controllers, this processor includes battery-backed SRAM. The lithium battery retains user programs during power outages. Consequently, the Honeywell 620-1030 maintains its logic for over one year without power. A supercapacitor provides temporary backup during battery replacement. This capacitor stores enough energy for 10 minutes of RAM retention. The module also uses flash memory for permanent firmware storage.
Installation and Mounting Requirements
Installing the Honeywell 620-1030 takes only a few minutes of work. The unit slides directly into a compatible rack slot. It also locks securely with top and bottom retaining clips. Always disconnect all power before inserting or removing this processor. The unit uses passive cooling through natural convection. This design eliminates fan noise and moving parts. The processor occupies a single slot in the main rack.
Integration with Honeywell Control Systems
This processor works seamlessly with Honeywell I/O modules and networks. It communicates with field devices via Modbus and proprietary protocols. Operators can connect a programming terminal to the RS-232 port. The Honeywell 620-1030 also supports remote monitoring and control functions. Consequently, this processor remains an excellent choice for system upgrades. The unit delivers consistent performance across a 0°C to 60°C temperature range.
