The Honeywell 51308307-175 module executes control logic for industrial processes. This controller module belongs to the Honeywell series for distributed control systems. The unit runs regulatory and sequential control programs with high reliability. Consequently, this module serves as the brain of automation architectures.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | 51308307-175 |
| Product Type | Controller Module |
| Processor Type | 32-bit RISC |
| Clock Speed | 100 MHz |
| Memory | 16 MB RAM, 8 MB Flash |
| Non-volatile Storage | 512 KB EEPROM |
| Control Capacity | 512 I/O points |
| Communication Ports | 2 x RS-232, 2 x RS-485 |
| Network Interface | 10/100 Ethernet |
| Scan Rate | 10 ms per 1K logic |
| Power Supply | 24 VDC ±20% |
| Power Consumption | 8 W typical |
| Dimensions | 210 x 185 x 45 mm |
| Weight | 0.85 kg |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH, non-condensing |
| Country of Origin | USA |
Processing Power and Memory Configuration
The 51308307-175 uses a 32-bit RISC processor running at 100 MHz. This processing power handles complex control algorithms with ease. The module includes 16 MB of RAM for runtime operations. An additional 8 MB of Flash memory stores the application firmware. The unit also features 512 KB of EEPROM for non-volatile data retention. Therefore, the Honeywell 51308307-175 retains critical parameters during power loss.
Control Capacity and Performance
This controller module supports up to 512 I/O points per unit. The scan rate reaches 10 ms per 1K of logic instructions. Consequently, the module responds quickly to process changes and alarms. The 51308307-175 executes both regulatory PID loops and sequential logic.
Communication Interfaces
The Honeywell 51308307-175 provides two RS-232 ports for local device connections. Two RS-485 ports support multi-drop field device networks. A 10/100 Ethernet port enables high-speed network integration. Therefore, this controller communicates seamlessly with HMIs, historians, and other controllers.
Power Requirements and Physical Dimensions
The 51308307-175 requires a 24 VDC power supply with ±20% tolerance. Typical power consumption measures 8 W for reliable operation. The module measures 210 x 185 x 45 mm for standard rack mounting. Total weight reaches 0.85 kg for secure installation. Honeywell manufactures this controller module in the USA. Accordingly, users receive high-quality performance for critical process applications.
Environmental Specifications
The controller module operates reliably from 0°C to +60°C. Storage temperatures range safely from -40°C to +85°C. Humidity tolerance spans 5% to 95% RH without condensation.
Details
| Weight | 0.2 kg |
|---|---|
| Dimensions | 85 × 65 × 30 mm |
