Ensuring Reliable Network Connectivity in Harsh Environments
The Honeywell 51305482-110 is a robust Field Termination Ethernet (FTE) cable. This 10-meter yellow cable ensures reliable data transmission for industrial automation networks. It performs consistently even in demanding and harsh industrial environments. Consequently, it is a critical component for mission-critical control system communication.
Technical Specifications and Physical Characteristics
This specific FTE cable from Honeywell features a durable double-shielded design. Its yellow PVC jacket provides high visibility and protection against physical damage. Furthermore, the cable supports a wide operating temperature range for versatile industrial use.
Detailed Technical Parameters
| Parameter | Specification |
|---|---|
| Manufacturer | Honeywell |
| Model Number | 51305482-110 |
| Cable Type | Field Termination Ethernet (FTE) |
| Primary Application | Honeywell Experion PKS & Fault Tolerant Ethernet Networks |
| Cable Length | 10 meters |
| Outer Jacket Color | Yellow |
| Shielding Type | Foil & Braid Combination (Double Shielded) |
| Conductor Material | High-Purity Copper |
| Insulation Material | PVC (Per Conductor) |
| Jacket Material | Industrial-Grade PVC |
| Operating Temperature Range | -20°C to +70°C |
| Storage Temperature Range | -40°C to +85°C |
| Nominal Operating Voltage | 24 VDC (for associated switch power/POE reference) |
| Signal Voltage | Standard Ethernet levels |
| Connector Type (Ends) | 8P8C (RJ45) |
| Connector Contacts | Gold-plated for corrosion resistance |
| Cable Weight | 0.35 kg (for the 10-meter length) |
| Bend Radius | Minimum 4x cable diameter |
| Flame Rating | Typically CM/CMR (Check local regulations for specific rating) |
| Attenuation & Crosstalk | Meets or exceeds TIA/EIA-568-B for Category 5e/6 performance |
| Packaging | Individual unit, coiled |
Key Features and Application Context
This cable connects FTE switches, controllers, and workstations within a Honeywell system. Its dual foil and braid shielding provides excellent immunity to electromagnetic interference (EMI). The robust PVC jacket resists oils, chemicals, and abrasion in industrial settings. Moreover, the standard RJ45 connectors ensure compatibility with a wide range of industrial Ethernet devices. This makes the 51305482-110 suitable for control rooms and plant floor installations.
Installation and System Integration Notes
Use this cable for point-to-point connections in an FTE network topology. Proper installation requires adhering to the minimum bend radius to prevent damage. Technicians should use appropriate cable ties and routing trays for strain relief. Furthermore, always verify connector mating and ensure the locking tab engages securely. This cable is a consumable component with no internal energy storage or active parts.
Reliability and Design for Mission-Critical Systems
Honeywell designs this cable for continuous operation in critical process environments. Its electrical characteristics maintain signal integrity over the full 10-meter length. The yellow color allows for easy identification among other plant cabling. Therefore, the 51305482-110 provides a dependable physical layer for your control network infrastructure.
Details
| Weight | 0.68 kg |
|---|---|
| Dimensions | 145 × 100 × 40 mm |
